Asrock B450 Steel Legend Motherboard
2695 جنية
- MODEL : MXBA00-A0UAYZ-90
- AMD Promontory B450
- Supports AMD Ryzen 5000 / 3000 / 2000 Series Processors
- DDR4 3533+(OC) / 3200(OC) / 2933(OC) / 2667 / 2400 / 2133 (AMD Ryzen series CPUs (Pinnacle Ridge))
- DDR4 3466+(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133 (AMD Ryzen series CPUs (Raven Ridge))
- DDR4 3466+(OC) / 3200(OC) / 2933(OC) / 2667 / 2400 / 2133 (AMD Ryzen series CPUs (Summit Ridge))
- DDR4 3200 / 2933 / 2667 / 2400 / 2133 (AMD Ryzen series CPUs (Vermeer & Matisse), APUs (Renoir))
- DDR4 2933 / 2667 / 2400 / 2133 (AMD Ryzen series CPUs (Picasso))
Brand | ASRock |
---|---|
Model | B450 Steel Legend |
CPU Socket Type | AM4 |
---|---|
CPU Type | Supports AMD Ryzen 5000 / 3000 / 2000 Series Processors |
Chipset | AMD Promontory B450 |
---|
Number of Memory Slots | 4x288pin (DDR4) |
---|---|
Memory Standard | DDR4 3533+(OC) / 3200(OC) / 2933(OC) / 2667 / 2400 / 2133 (AMD Ryzen series CPUs (Pinnacle Ridge))
DDR4 3466+(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133 (AMD Ryzen series CPUs (Raven Ridge)) DDR4 3466+(OC) / 3200(OC) / 2933(OC) / 2667 / 2400 / 2133 (AMD Ryzen series CPUs (Summit Ridge)) DDR4 3200 / 2933 / 2667 / 2400 / 2133 (AMD Ryzen series CPUs (Vermeer & Matisse), APUs (Renoir)) DDR4 2933 / 2667 / 2400 / 2133 (AMD Ryzen series CPUs (Picasso)) |
Maximum Memory Supported | 128GB |
Channel Supported | Dual Channel |
ECC Supported | For Ryzen Series APUs (Picasso, Renoir and Raven Ridge), ECC is only supported with PRO CPUs. |
Buffer Supported | Un-buffered |
PCI Express 3.0 x16 | 2 x PCI Express 3.0 x16*
* Actual support may vary by CPU. |
---|---|
PCI Express x1 | 4 x PCI Express 2.0 x1 |
SATA 6Gb/s | 6 x SATA 6Gb/s*
* M2_2, SATA3_3 and SATA3_4 share lanes. If either one of them is in use, the others will be disabled. |
---|---|
M.2 | 1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 PCI Express module up to Gen3 x4 (32 Gb/s) (with Vermeer, Matisse, Renoir, Picasso, Summit Ridge, Raven Ridge and Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with Athlon series APU and Raven Ridge 2)**
1 x M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x2 (16 Gb/s)** ** If M2_1 is occupied, PCIE4 will be disabled. |
SATA RAID | 0/1/10 |
Onboard Video Chipset | Supported only by CPU with integrated graphic |
---|
Audio Chipset | Realtek ALC892/897 |
---|---|
Audio Channels | 7.1 Channels |
LAN Chipset | Realtek RTL8111H |
---|---|
Max LAN Speed | 10/100/1000Mbps |
Back I/O Ports | 1 x PS/2 Mouse/Keyboard Port 1 x HDMI Port 1 x DisplayPort 1.2 1 x Optical SPDIF Out Port 2 x USB 2.0 Ports (Supports ESD Protection) 1 x USB 3.1 Gen2 Type-A Port (10Gb/s) (Supports ESD Protection) 1 x USB 3.1 Gen2 Type-C Port (10Gb/s) (Supports ESD Protection) 4 x USB 3.1 Gen1 Ports (Supports ESD Protection)* 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks)* Ultra USB Power is supported on USB3_34 ports. * ACPI wake-up function is not supported on USB3_34 ports. |
---|
Onboard USB | 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection) |
---|---|
Other Connectors | 1 x COM Port Header 1 x TPM Header 1 x Power LED and Speaker Header 1 x RGB LED Header* 1 x Addressable LED Header** 1 x AMD Fan LED Header*** 1 x CPU Fan Connector (4-pin)**** 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***** 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)****** 1 x Front Panel Audio Connector* Supports in total up to 12V/3A, 36W LED Strip. ** Supports in total up to 5V/3A, 15W LED Strip. *** The AMD Fan LED Header supports LED strips of maximum load of 3A (36W) and length up to 2.5M. **** The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ***** The CPU/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. ****** The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. ****** CPU_FAN2/WP, CHA_FAN1/WP, CHA_FAN2/WP and CHA_FAN3/WP can auto detect if 3-pin or 4-pin fan is in use. |
Form Factor | ATX |
---|---|
LED Lighting | RGB |
Dimensions (W x L) | 12.0″ x 9.6″ |
Power Pin | 1 x 24-pin ATX Power Connector 1 x 8-pin 12V Power Connector |
Windows 11 | Supported |
---|
Features | Unique Feature: ASRock USB 3.1 Gen2 – ASRock USB 3.1 Gen2 Type-A Port (10Gb/s) – ASRock USB 3.1 Gen2 Type-C Port (10Gb/s) ASRock Super Alloy – XXL Aluminum Alloy Heatsink – Premium 60A Power Choke – Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) – I/O Armor – Sapphire Black PCB – High Density Glass Fabric PCB – 2oz Copper PCB ASRock Steel Slot ASRock Full Coverage M.2 Heatsink ASRock Ultra M.2 (PCIe Gen3 x4) ASRock Ultra USB Power ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update & APP Shop AMD StoreMIBIOS: – 128MB AMI UEFI Legal BIOS with multilingual GUI support – Supports “Plug and Play” – ACPI 5.1 compliance wake up events – Supports jumperfree – SMBIOS 2.3 support – DRAM Voltage multi-adjustment Software and UEFI: Support CD: Hardware Monitor: OS: Certifications: |
---|
Package Contents | Accessories: – Quick Installation Guide, Support CD, I/O Shield – 2 x SATA Data Cables – 2 x Screws for M.2 Sockets – 1 x Standoff for M.2 Socket |
---|
