Asus Rog Maximus Z890 HERO Motherboard
29130 جنيه
- • رقم القطعة: 90MB1ID0-M0EAY0
- • Form Factor & Design: ATX Form Factor (30.5 x 24.4 cm) | ROG Maximus Premium Aesthetic | Full Metal Backplate | Comprehensive M.2 & VRM Heatsinks | Pre-mounted I/O Shield | SafeSlot & SafeDIMM | Extreme OC Kit (FlexKey, ReTry, Start Buttons) | Q-Release Slim, M.2 Q-Latch, M.2 Q-Slide & Q-Code Diagnostics
- • Compatibility: Intel LGA1851 Socket | Intel Core Ultra Processors (Series 2) | 4 x DDR5 DIMM Slots (Max 256GB, up to 9200+ MT/s OC) | Supports Intel XMP, DIMM Flex, NitroPath DRAM Technology & AEMP III
- • Performance: Intel Z890 Chipset | 1x PCIe 5.0 x16 & 1x PCIe 4.0 x16 (x4 mode) | 6x M.2 Slots (3x PCIe 5.0, 3x PCIe 4.0) & 4x SATA 6Gb/s & 1x SlimSAS | Wi-Fi 7 (802.11be) & Bluetooth v5.4 | Dual Ethernet (Intel 2.5Gb + Realtek 5Gb) | ROG SupremeFX ALC4082 7.1 HD Audio with ESS ES9219 QUAD DAC | 2x Thunderbolt™ 4 (USB-C) | Front USB 20Gbps Type-C with 60W Power Delivery
- • الضمان: 3 Years Manufacturer Warranty
متوفر في المخزون
ضمان مطابقة السعرAsus Rog Maximus Z890 HERO اللوحات الأم
Asus Rog Maximus Z890 HERO اللوحات الأم
Specifications:
- CPU Support: Intel® Core™ Ultra Processors (Series 2), LGA1851
- Chipset: Intel® Z890 Chipset
- Memory: 4 x DIMM slots, max. 192GB, DDR5 (up to 9200+MT/s)
- Graphics: 1 x HDMI™ port, 2 x Intel® Thunderbolt™ 4 ports (USB Type-C®) support DisplayPort and Thunderbolt™ video outputs
- Expansion Slots:
- 1 x PCIe 5.0 x16 slot
- 1 x PCIe 4.0 x16 slot
- 1 x PCIe 4.0 x1 slot
- Storage: Up to 6 x M.2 slots, 1 x SlimSAS connector and 4 x SATA 6Gb/s ports
- Networking: 1 x Intel® 2.5Gb Ethernet, 1 x Realtek 5Gb Ethernet, Wi-Fi 7
- USB:
- Rear: 11 ports (2 x Thunderbolt™ 4, 5 x USB 10Gbps, 4 x USB 5Gbps)
- Front: 10 ports (1 x USB 20Gbps, 1 x USB 10Gbps, 2 x USB 5Gbps headers, 2 x USB 2.0 headers)
- Audio: ROG SupremeFX 7.1 Surround Sound High-Definition Audio CODEC ALC4082
- Form Factor: ATX
- Dimensions: 12-inch x 9.6 inch (30.5 cm x 24.4 cm)
اللوحة الأم
| MODEL | |
|---|---|
| CHIPSET MANUFACTURERS | |
| سوكت المعالج | |
| شريحة اللوحة الأم | |
| Motherboard Type | |
| CPU SERIES | |
| Technology | |
| Memory Speed | 5600 MHz, 5800 MHz, 6000 MHz, 6200 MHz, 6400 MHz, 6600 MHz, 6800 MHz, 7000 MHz, 7200 MHz, 7400 MHz, 7600 MHz, 7800 MHz, 8000 MHz, 8200 MHz, 8266 MHz, 8400 MHz, 8600 MHz, 8800 MHz, 8933 MHz, 9066 MHz, 9200 MHz |
| Max Memory Size | |
| Memory Slot | |
| PCI-E X16 | |
| PCI-E GEN | PCIe 5.0 |
| PCI-E Slots (M.2) | |
| SATAIII | |
| Communication module | |
| Part Number | |
| الضمان |
