Gigabyte X870E Aorus Elite Wifi 7 v1.2 Ice Gaming Motherboard

Gigabyte X870E Aorus Elite Wifi 7 v1.2 Ice Gaming اللوحات الأم:

The Gigabyte X870E Aorus Elite Wifi 7 v1.2 Ice Gaming Motherboard is a premium foundation for building a high-performance AMD Ryzen system, designed with a striking white aesthetic. This motherboard supports the latest AMD Ryzen™ 9000, 8000, and 7000 Series Processors on the AM5 socket, ensuring cutting-edge performance for gaming, content creation, and demanding applications. Furthermore, its comprehensive feature set, including advanced power delivery and next-gen connectivity, makes it an ideal choice for enthusiasts.

Unleash Extreme Performance and Connectivity:

The X870E Aorus Elite Wifi 7 v1.2 Ice boasts a robust 16*+2+2 Twin Digital VRM Design, ensuring stable and efficient power delivery to the CPU even under heavy loads. It supports dual-channel DDR5 memory, allowing for up to 256GB of system memory with speeds reaching an impressive 8200MHz (OC) via AMD EXPO™ and XMP profiles. This robust memory support is critical for maximizing performance in memory-intensive tasks and games.

For storage and expansion, this motherboard is equipped with four M.2 slots, including three PCIe 5.0 x4 M.2 UD Slots and one PCIe 4.0 M.2 slot, providing ultra-fast storage options for your operating system and games. It also features a PCIe 5.0 x16 slot with GIGABYTE’s innovative PCIe UD Slot X, offering 10X load-bearing capacity for enhanced durability and protection for your high-end graphics card. Additionally, a 2.5GbE LAN and Wi-Fi 7 with an ultra-high gain antenna deliver blazing-fast wired and wireless networking, perfect for online gaming and high-bandwidth applications.

The X870E Aorus Elite Wifi 7 v1.2 Ice also offers extensive connectivity, including dual USB4 Type-C ports (up to 40Gb/s with DisplayPort Alt Mode), multiple USB 3.2 Gen 2 and Gen 1 ports, and a front USB-C 20Gb/s header. Audio is handled by the Realtek ALC1220 HD Audio codec with audiophile-grade capacitors, providing immersive 7.1-channel high-definition sound. Features like Q-FLASH Plus Button and Smart Fan 6 further enhance the user experience by simplifying BIOS updates and providing precise fan control for optimal cooling and quiet operation.

Explore compatible المعالجات or check Gigabyte Products for other options. Find full details on the official Gigabyte X870E Aorus Elite Wifi 7 v1.2 Ice Gaming Motherboard product page.

Specifications:

• CPU Socket: AM5 (Supports AMD Ryzen™ 9000/8000/7000 Series Processors)
• Chipset: AMD X870E
• Memory Support: 4 x DDR5 DIMM sockets, up to 256 GB, Dual Channel, supports 8200(OC) to 4400 MT/s
• Expansion Slots:
  • 1 x PCIe 5.0 x16 slot (from CPU, with PCIe UD Slot X)
  • 1 x PCIe 4.0 x4 slot (from Chipset)
  • 1 x PCIe 3.0 x2 slot (from Chipset)
• Storage Interface:
  • 3 x PCIe 5.0 x4 M.2 slots
  • 1 x PCIe 4.0 x4 M.2 slot
  • 4 x SATA 6Gb/s connectors (supports RAID 0, 1, 5, 10)
• USB Ports (Rear I/O):
  • 2 x USB4® Type-C® (with DisplayPort)
  • 2 x USB 3.2 Gen 2 Type-A (red)
  • 4 x USB 3.2 Gen 1
  • 4 x USB 2.0/1.1
• Networking: Realtek® 2.5GbE LAN, Wi-Fi 7 (MediaTek MT7925 or Realtek RTL8922AE), Bluetooth 5.4
• Audio: Realtek® ALC1220 CODEC, 7.1-channel High Definition Audio
• Display Outputs: 2 x USB4® Type-C® (DisplayPort), 1 x HDMI (HDMI 2.1)
• Form Factor: ATX (30.5cm x 24.4cm)
• Model Number/SKU: X870 AORUS ELITE WIFI7 ICE
• EAN/UPC: 889523045176
