Msi Mag X870E Tomahawk Wifi Motherboard

Msi Mag X870E Tomahawk Wifi اللوحه الام

The Msi Mag X870E Tomahawk Wifi Motherboard is designed for gamers, providing a stable, durable, and DIY-friendly foundation for high-performance PC builds. Ready for the battlefield with support for AMD Ryzen™ 9000, 8000, and 7000 series processors (Socket AM5), this motherboard comes equipped with cutting-edge features including Wi-Fi 7, 5G LAN, dual USB4 40Gbps ports, PCIe 5.0 solutions for both graphics and storage, and exclusive EZ DIY enhancements.

Discover Next-Gen Gaming Power: MAG X870E TOMAHAWK WIFI

Built to withstand intense gaming sessions, the MAG X870E TOMAHAWK WIFI features a robust 14+2+1 Duet Rail Power System (80A SPS) and dual 8-pin CPU power connectors to unleash maximum performance from high-end processors. Furthermore, cooling is prioritized with an Extended Heatsink Design, high-quality 7W/mK MOSFET thermal pads, additional choke pads, and M.2 Shield Frozr for key storage slots, ensuring stability under heavy loads. The optimized 8-layer PCB with 2oz thickened copper enhances signal transmission and heat dissipation.

Experience lightning-fast connectivity and expansion. The primary PCIe slot supports the latest PCIe 5.0 x16 standard (CPU dependent). Storage options are abundant and incredibly fast, featuring dual CPU-connected PCIe 5.0 x4 M.2 slots alongside two chipset-connected PCIe 4.0 x4 M.2 slots. Networking reaches new speeds with onboard 5G LAN and the latest Wi-Fi 7 solution supporting 6GHz bands and up to 5.8Gbps throughput, complemented by Bluetooth 5.4. Additionally, dual rear USB4 40Gbps Type-C ports offer unparalleled data transfer speeds and display capabilities.

MSI’s EZ DIY features make building easier than ever. These include the EZ PCIe Release button, pre-installed I/O shield, EZ Antenna, EZ Debug LEDs, and EZ M.2 Clips. High-performance DDR5 memory support reaches speeds up to 8400+ MT/s (OC) with AMD EXPO™ profiles. Moreover, the Realtek ALC4080 codec delivers high-performance 7.1 channel audio. Explore compatible AMD Ryzen CPUs or browse other MSI Motherboards. Find full details on the official MSI MAG X870E TOMAHAWK WIFI product page.

Specifications

• Model Name: MAG X870E TOMAHAWK WIFI
• Chipset: AMD X870E
• CPU Socket: AM5
• CPU Support: AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
• Memory: 4x DDR5 UDIMM, Max 256GB, 8400+(OC) MT/s, EXPO™
• PCIe Slots: 1x PCIe 5.0 x16 (CPU), 1x PCIe 4.0 x4 (Chipset), 1x PCIe 3.0 x1 (Chipset)
• Storage: 2x M.2 PCIe 5.0 x4 (CPU), 2x M.2 PCIe 4.0 x4 (Chipset), 4x SATA 6Gb/s
• Networking: Realtek 5G LAN, Wi-Fi 7 (802.11be), Bluetooth 5.4
• Audio: Realtek ALC4080 Codec (7.1 Channel USB High Performance Audio)
• Rear USB: 2x USB 40Gbps (Type-C, DP 1.4), 1x USB 10Gbps (Type-C), 2x USB 10Gbps (Type-A), 3x USB 5Gbps (Type-A), 4x USB 2.0 (Type-A)
• Front USB Headers: 1x USB 20Gbps (Type-C), 4x USB 5Gbps (Type-A), 4x USB 2.0 (Type-A)
• Form Factor: ATX (243.84mm x 304.8mm)
• Features: 14+2+1 Power Design (80A SPS), Extended Heatsink, M.2 Shield Frozr, PCIe 5.0 Slot & M.2, 5G LAN, Wi-Fi 7, Dual USB4, EZ DIY Features (PCIe Release, Antenna, Debug LEDs, M.2 Clip), Pre-installed I/O Shield, Supplemental PCIe Power Connector
