Thermaltake Core P6 Tg Mid Tower Case

THERMALTAKE CORE P6 TG

• P/N CA-1V2-00M1WN-00
• SERIES Core
• MODEL Core P6 TG
• CASE TYPE Mid Tower
• DIMENSION (H X W X D) 565 x 255 x 530mm – (22.2 x 10 x 20.9 inch)
• NET WEIGHT 17.84 kg / 39.33 lbs.
• SIDE PANEL 4mm Tempered Glass x 3
• COLOR Black
• MATERIAL SPCC
• COOLING SYSTEM –
• DRIVE BAYS
• -ACCESSIBLE
• -HIDDEN 4 x 3.5” or 8 x 2.5”
• EXPANSION SLOTS 7 (Rotatable Patented Design)
• MOTHERBOARDS 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), – 12” x 9.6” (ATX), 12” x 10.5”(CEB)
• I/O PORT USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1
• PSU Standard PS2 PSU (optional)
• FAN SUPPORT
  Front:
  3 x 120mm, 2 x 120mm, 1 x 120mm
  2 x 140mm, 1 x 140mm
  Top:
  3 x 120mm, 2 x 120mm, 1 x 120mm
  2 x 140mm, 1 x 140mm
  Rear:
  1 x 120mm
  Right (M/B Side):
  3 x 120mm, 2 x 120mm, 1 x 120mm
  2 x 140mm, 1 x 140mm
  Bottom:
  3 x 120mm, 2 x 120mm or 1 x 120mm
  2 x 140mm, 1 x 140mm
• RADIATOR SUPPORT
  Front:
  1 x 360mm, 1 x 240mm, 1 x 120mm
  1 x 280mm, 1 x 140mm
  Top:
  1 x 360mm, 1 x 240mm, 1 x 120mm
  1 x 280mm, 1 x 140mm
  Rear:
  1 x 120mm
  Right (M/B Side):
  1 x 360mm, 1 x 240mm, 1 x 120mm
  1 x 280mm, 1 x 140mm
  Bottom:
  1 x 240mm, 1 x 120mm
• CLEARANCE
  CPU cooler height limitation:
  180mm
  VGA length limitation:
  300mm (With Reservoir)
  400mm (Without Reservoir)
  430mm (With Radiator)
  458mm (Without Radiator)
  PSU length limitation:
  200mm
