Series

S Series

Dimension (H x W x D)

490 x 218 x 462 mm

(19.3 x 8.6 x 18.2 inch)

Net Weight

7.5 kg / 16.53 lbs.

Panel

4mm Tempered Glass x 1

اللون

اسود

Material

SPCC

Cooling System

Front (Intake): 120 x 120 x 25 mm CT120 ARGB fan (2000rpm, 25.8 dBA) x 3

Rear (Exhaust): 120 x 120 x 25 mm CT120 ARGB fan (2000rpm, 25.8 dBA) x 1

Drive Bays

2 x 3.5”, 2 x 2.5” or 4 x 2.5”

Expansion Slots

7

Motherboards

Mini ITX (6.7” x 6.7”)

Micro ATX (9.6” x 9.6”)

ATX (12” x 9.6”)

E-ATX (12” x 13”)

I/O Port

USB 3.0 x 2, HD Audio x 1

باور سبلاي

Standard ATX PSU (optional)

Fan Support

Front:

3 x 120mm, 2 x 120mm, 1 x 120mm

3 x 140mm, 2 x 140mm, 1 x 140mm

Top:

3 x 120mm, 2 x 120mm, 1 x 120mm,

2 x 140mm, 1 x 140mm

Right(M/B Side):

2 x 120mm, 1 x 120mm

Rear: 1 x 120mm

Power Cover:

2 x 120mm, 1 x 120mm

Radiator Support

Front:

1 x 360mm, 1 x 240mm, 1 x 120mm

1 x 420mm, 1 x 280mm, 1 x 140mm

Top:

1 x 360mm, 1 x 240mm, 1 x 120mm

1 x 280mm, 1 x 140mm

Right(M/B Side):1 x 240mm, 1 x 120mm

Rear: 1 x 120mm

Clearance

CPU cooler height limitation: 165mm

VGA length limitation: 400mm

PSU length limitation: 220mm
