Xpg Core Reactor II 850W 80 Plus Gold White Fully Modular Power Supply
7000 جنية
- 850W Single +12V Rail
- Intel ATX 3.0 12V Form Factor
- 12VHPWR 16-Pin Connector
- 6 x PCIe Connectors
- 8 x SATA Connectors
- 4 x Molex Connectors
- 80 PLUS Gold Efficiency
- Modular Design
- 120mm Internal Cooling Fan
- Intelligent Fan Curve
المتوفر في المخزون 1 فقط
Xpg Core Reactor II 850W 80 Plus Gold White Fully Modular Power Supply
-
Next-Gen Ready – ATX 3.0 & ATX 3.1 COMPLIANT
- CORE REACTOR II series power supply units meet Intel ATX 3.0 & ATX 3.1 design guide specifications and feature a 12VHPWR connector. By upgrading to an ATX 3.0 & ATX 3.1-compliant power supply, you’ll be fully equipped for the upcoming wave of high-performance components. A must for the modern gamer, creator, or AI developer. Stay ahead of the curve by upgrading to an ATX 3.0 & ATX 3.1 PSU, the new standard in PC hardware.
-
Dimensions (L x W x H)
- 650W-850W: 140 x 150 x 86mm
1000W-1200W: 160 x 150 x 86mm -
Cybenetics Rating
- 1200W: PLATINUM
- 1000W: PLATINUM
- 850W: PLATINUM
- 750W: PLATINUM
- 650W: PLATINUM
-
80 Plus Rating
- GOLD
-
ATX Version
- ATX 3.0 & ATX 3.1
-
Protections
- OCP | OVP | OPP | OTP | UVP | SCP | NLO | SIP
-
Certification
- CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Mark | NOM | BSMI | UKCA | EAC | CCC | RCM
-
PFC
- > 0.99
-
Input Voltage
- 100-240V
-
Input Current
- 1200W: 15A
- 1000W: 13A
- 850W: 12A
- 750W: 10A
- 650W: 10A
-
Input Frequency
- 650/750/850/1000/1200W:47Hz-63Hz
-
DC Output Voltage
- +5V | +3.3V | +12V | -12V | +5Vsb
-
Total Output
- 1200W: +5V/+3.3V :22A, +12V:100A, -12V:0.3A, +5Vsb:3A
- 1000W: +5V/+3.3V :22A, +12V:83.5A, -12V:0.3A, +5Vsb:3A
- 850W: +5V/+3.3V :22A, +12V:70.8A, -12V:0.3A, +5Vsb:3A
- 750W: +5V/+3.3V :22A, +12V:62.5A, -12V:0.3A, +5Vsb:3A
- 650W: +5V/+3.3V :20A, +12V:54.1A, -12V:0.3A, +5Vsb:3A
-
Power Excursion
- 1200W: 2820W(*up to 235% of the PSU’s rated power for 100μs)
- 1000W: 2350W(*up to 235% of the PSU’s rated power for 100μs)
- 850W: 1997W (*up to 235% of the PSU’s rated power for 100μs)
- 750W: 1762W (*up to 235% of the PSU’s rated power for 100μs)
- 650W: 1527W(*up to 235% of the PSU’s rated power for 100μs)
-
Operating Temperature
- 50°C
-
Fan Size
- 650W-850W: 120mm FDB Fan
- 1000W-1200W: 135mm FDB Fan
-
Fan Bearin
- FDB (Fluid Dynamic Bearing)
-
Fan Speed
- 2400 RPM
-
MTBF
- 100K hours at full load
-
ATX 24 Pin Connector
- 1200W/1000W:1
- 850W/750W/650W:1
-
EPS 8 Pin Connector
- 1200W/1000W:2
- 850W/750W/650W:2
-
PCI-E 6+2 Pin Connector
- 1200W/1000W:8
- 850W/750W:6
- 650W:4
-
12VHPWR (12 + 4) Connector (600W)
- 1200W/1000W/850W/750W: 1
-
12VHPWR (12 + 4) Connector (450W)
- 650W:1
-
SATA Connector
- 1200W/1000W:9
- 850W/750W/650W:8
-
Weight
- 1200W/1000W:
- Product+cables：1.77kg+1.28kg
- with Package:3.43kg
- 850W/750W:
- Product+cables：1596g+1254g
- with Package:3.1kg
- 650W:
- Product+cables：1299g+1231g
- with Package:2.78kg
