Asrock X870 Pro RS WiFi Motherboard

ASRock X870 Pro RS WiFi اللوحات الأم

The ASRock X870 Pro RS WiFi Motherboard represents the evolution of the popular PRO series, offering a modern and futuristic design with a perfect balance of attractive specifications. Engineered for superb productivity and rock-solid durability, this motherboard integrates cutting-edge technologies like PCIe Gen5, DDR5 memory support, and USB4 Type-C ports. Furthermore, it ensures ultrafast connectivity with 2.5G LAN and Wi-Fi 7, making it an ideal foundation for high-performance AMD Ryzen™ systems.

---

Unleash Next-Gen Performance and Connectivity:

Experience unparalleled computing power with the ASRock X870 Pro RS WiFi. This motherboard is designed to support the latest AMD Socket AM5 Ryzen™ 9000, 8000, and 7000 Series Processors. It provides a robust platform for demanding applications and gaming. Moreover, its advanced features ensure that your system operates at peak efficiency and speed.

Cutting-Edge Processor and Memory Support:

The X870 Pro RS WiFi fully supports Dual Channel DDR5 Memory Technology. It features 4 DDR5 DIMM slots, allowing for a maximum system memory capacity of 256GB. It also supports DDR5 ECC/non-ECC, un-buffered memory up to an impressive 8000+(OC) MHz. Additionally, the motherboard supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules. Consequently, this ensures optimal memory performance for all your tasks.

Blazing-Fast PCIe Gen5 and M.2 Storage:

Benefit from lightning-fast data transfer speeds with PCIe Gen5. The motherboard includes a PCIe 5.0 x16 slot for graphics, ensuring maximum bandwidth for the latest GPUs. Furthermore, it features a Blazing M.2 Socket (M2_1) that supports PCIe Gen5x4 mode, delivering speeds up to 128 Gb/s for ultra-fast NVMe SSDs. In addition, it provides a Hyper M.2 Socket (Gen4x4) and an Ultra M.2 Socket (SATA3 & PCIe Gen3x4), offering flexible storage options. The motherboard also supports RAID 0, 1, and 10 for M.2 NVMe storage devices, as well as RAID 0 and 1 for SATA drives.

---

Robust Durability and Ultrafast Networking:

The ASRock X870 Pro RS WiFi Motherboard is built for enduring stability and superior network performance. Its robust power delivery system ensures reliable operation under heavy loads. Additionally, state-of-the-art wireless and wired networking capabilities provide seamless and high-speed connectivity for all your online activities.

Rock-Solid Power Delivery and Cooling:

This motherboard features a robust 14+2+1 Power Phase design, incorporating 80A Dr.MOS for VCore, SOC, and MISC components. This ensures stable and efficient power delivery to the CPU and other critical parts. An enlarged heatsink armor effectively dissipates heat, maintaining optimal temperatures even during intense workloads. Moreover, the flexible integrated I/O Shield simplifies installation and provides enhanced durability.

Next-Gen Wi-Fi 7 and 2.5G LAN:

Experience the future of wireless connectivity with the integrated 802.11be 2×2 Wi-Fi 7 Module. This module supports 2.4GHz, 5GHz, and 6GHz frequency bands, including 160MHz channel bandwidth with 6GHz for incredibly fast speeds. It also features Bluetooth 5.4 and MU-MIMO technology. For wired connections, the Dragon RTL8125BG 2.5 Gigabit LAN provides blazing-fast 10/100/1000/2500 Mb/s speeds. Furthermore, the Dragon 2.5G LAN Software offers Smart Auto Adjust Bandwidth Control and optimized settings for gaming, browsing, and streaming. Please note that the Wi-Fi 7 module is supported by Microsoft Windows® 11 only.

---

Advanced Features and User-Friendly Design:

The ASRock X870 Pro RS WiFi Motherboard integrates a variety of advanced features and user-friendly tools. These enhance system functionality, simplify troubleshooting, and offer extensive customization options. From high-fidelity audio to convenient BIOS management, this motherboard provides a comprehensive and intuitive experience.

Comprehensive Connectivity with USB4:

The motherboard offers extensive connectivity options. It includes two rear USB4 Type-C ports, delivering blazing-fast 40 Gb/s data transfer speeds and supporting USB PD 3.0 up to 15W charging. Additionally, it features a front USB 3.2 Gen2x2 Type-C header (20 Gb/s), multiple USB 3.2 Gen1 Type-A ports (both rear and front), and numerous USB 2.0 ports. Moreover, all USB ports come with ESD Protection, ensuring device safety.

Immersive Audio and Convenient Management:

Enjoy crystal-clear audio with 7.1 CH HD Audio, powered by the Realtek ALC1220 Audio Codec and enhanced by Nahimic Audio. Furthermore, the motherboard includes convenient management features such as a BIOS Flashback Button for easy firmware updates without a CPU, and ASRock Auto Driver Installer for hassle-free driver setup. As a result, the ASRock Post Status Checker simplifies troubleshooting by indicating system status during boot-up.

Customizable Lighting and Fan Control:

Personalize your build with ASRock Polychrome SYNC, which allows you to synchronize RGB lighting across compatible components. The motherboard includes RGB LED and Addressable LED headers for connecting LED strips. In addition, comprehensive fan control is provided through two CPU fan connectors, four chassis fan connectors, and an AIO pump fan connector. All these support Smart Fan Speed Control for optimal cooling and acoustics.

---

Key Specifications:

Processor & Chipset:

• CPU Support: AMD Socket AM5 Ryzen™ 9000, 8000, and 7000 Series Processors
• Chipset: AMD X870

Memory & Graphics:

• Memory:
  • Dual Channel DDR5 Memory Technology
  • 4 x DDR5 DIMM Slots
  • Supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC) MHz
  • Max. capacity: 256GB
  • Supports XMP and EXPO memory modules
• Graphics: Integrated AMD RDNA™ graphics (actual support varies by CPU)
  • 1 x HDMI 2.1 (up to 4K 120Hz)
  • 2 x USB4 (up to 8K 30Hz, CPU’s embedded graphics only)

Audio & Networking:

• Audio: 7.1 CH HD Audio (Realtek ALC1220 Codec) with Content Protection, Nahimic Audio
• LAN: 2.5 Gigabit LAN (Dragon RTL8125BG)
• Wireless LAN: 802.11be 2×2 Wi-Fi 7 Module (2.4GHz/5GHz/6GHz, Bluetooth 5.4, MU-MIMO)

Expansion & Storage:

• Expansion Slots:
  • 1 x PCIe 5.0 x16 Slot (PCIE1)
  • 1 x PCIe 4.0 x16 Slot (PCIE2, supports x4 mode)
  • 1 x M.2 Socket (Key E) for WiFi/BT module
  • Supports AMD CrossFire™
  • 15μ Gold Contact in VGA PCIe Slot (PCIE1)
• Storage:
  • 1 x Blazing M.2 Socket (M2_1, PCIe Gen5x4)
  • 1 x Hyper M.2 Socket (M2_2, PCIe Gen4x4)
  • 1 x Ultra M.2 Socket (M2_3, SATA3 & PCIe Gen3x4)
  • 4 x SATA3 6.0 Gb/s Connectors
  • Supports RAID 0/1 for SATA, RAID 0/1/10 for M.2 NVMe

USB & Internal Connectors:

• USB Ports:
  • 2 x USB4 Type-C (Rear, 40 Gb/s, supports USB PD 3.0 up to 15W charging)
  • 1 x USB 3.2 Gen2x2 Type-C (Front)
  • 6 x USB 3.2 Gen1 Type-A (4 Rear, 2 Front)
  • 9 x USB 2.0 (6 Rear, 3 Front)
• Internal Connectors: Thermistor Cable Header, SPI TPM Header, Power LED/Speaker Header, RGB LED Header, 3 x Addressable LED Headers, 2 x CPU Fan Connectors, 4 x Chassis Fan Connectors, 1 x AIO Pump Fan Connector, 24 pin ATX Power, 2 x 8 pin 12V Power, Front Panel Audio, USB 2.0 Headers, USB 3.2 Gen1 Header, Front Panel Type C USB 3.2 Gen2x2 Header

Rear Panel I/O & Software:

• Rear Panel I/O: 2 x Antenna Ports, 1 x HDMI, 1 x Optical SPDIF Out, 2 x USB4 Type-C, 4 x USB 3.2 Gen1 Type-A, 6 x USB 2.0, 1 x RJ-45 LAN, 1 x BIOS Flashback Button, Line Out Jack, Microphone Input Jack
• Software & UEFI: ASRock Motherboard Utility (A-Tuning), Dragon 2.5G LAN Software, Polychrome SYNC, EZ Mode, Full HD UEFI, Auto Driver Installer, Instant Flash

Form Factor & Certifications:

• Form Factor: ATX (12.0-in x 9.6-in, 30.5 cm x 24.4 cm), 8 Layer PCB
• OS Support: Microsoft Windows® 10 64-bit / 11 64-bit
• Certifications: FCC, CE, ErP/EuP ready
• Model Number/SKU: 90-MXBQ00-A0UAYZ

---

For more detailed information, memory support lists, and driver downloads, please visit the official ASRock X870 Pro RS WiFi product page.
