Asrock X870 Steel Legend WiFi Motherboard
13649 جنيه
- Part Number 90-MXBPJ0-A0UAYZ
- سوكت المعالج AM5 (Supports AMD Ryzen™ 9000, 8000, and 7000 Series)
- Memory Support 4x DDR5 DIMM, up to 8000+(OC) MT/s (256GB Max)
- Primary Expansion Slot 1x PCIe 5.0 x16 (Gen 5 Ready)
- Storage Interface 3x M.2 Slots (1x Blazing Gen5x4, 2x Hyper Gen4x4)
- Networking Wi-Fi 7 (802.11be) & 2.5G LAN
- Connectivity 2x USB4 Type-C (40 Gb/s) & HDMI 2.1
- الضمان 3 Years
متوفر في المخزون
ضمان مطابقة السعر
Asrock X870 Steel Legend WiFi: Rock-Solid AM5 Thermal Engineering
In short, the Asrock X870 Steel Legend WiFi technically facilitates a superior architectural environment through its philosophical state of rock-solid durability. Notably, the architecture utilizes a 14+2+1 Power Phase design with 80A Dr.MOS to effectively enhance voltage stability while maintaining irresistible aesthetics. Specifically, the integrated PCIe 5.0 slots for graphics and storage reinforce structural integrity for next-gen enthusiast builds near-instantaneously, ensuring your technical presence remains stable under extreme loads.
Furthermore, the dual USB4 Type-C ports ensure stability for extreme 40 Gb/s data transfer iterations. Because the frame supports Wi-Fi 7 and 2.5G LAN, it technically facilitates elite ultrafast connectivity excursions without the latency compromise typical of standard boards. Consequently, the Steel Legend delivers a disciplined industrial aesthetic that blends premium 20K Black Caps with an 8-layer PCB design. As a result, you receive a visually perfect housing for your high-performance Ryzen 9000 series workstation.
Official ASRock Technical Product Page
Next-Gen Hardware & Thermal Synchronization
Advanced Power Telemetry
Notably, the Steel Legend architecture specifically utilizes a 14+2+1 Phase power design. This technically allows for extreme overclocking stability while effectively acting as a secondary thermal buffer through enlarged heatsink armor. Consequently, your technical presence remains stable during high-load professional rendering iterations.
Blazing M.2 Bandwidth
Moreover, the internal PCIe Gen5 M.2 socket effectively supports extraordinary transfer speeds up to 128 Gb/s. This architecture ensures your high-performance storage transitions remain clean and secure, supporting enthusiast AMD builds near-instantaneously during sustained gaming excursions.
💡 Pro-Builder Tip: Firmware Optimization
To technically facilitate maximum compatibility with Ryzen 9000 series processors, utilize the BIOS Flashback button to update your firmware without installing a CPU. Specifically, ensure you trigger the ASRock Auto Driver Installer to effectively synchronize your Wi-Fi 7 and 2.5G LAN drivers during your initial OS iteration.
Technical Matrix
| Hardware Feature | Detailed Specification |
|---|---|
| Chipset | AMD X870 |
| CPU Support | AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series |
| Memory | 4 x DDR5 DIMM, Supports up to 8000+(OC), Max 256GB |
| Graphics Output | 1 x HDMI 2.1, 2 x USB4 Type-C (Supports 8K 30Hz) |
| Audio | 7.1 CH HD Audio, Realtek ALC4082, Nahimic Audio |
| LAN | 2.5 Gigabit LAN (Dragon RTL8125BG) |
| Wireless | 802.11be Wi-Fi 7 Module, Bluetooth 5.4 |
| PCIe Slots | 1 x PCIe 5.0 x16, 1 x PCIe 4.0 x16 (x4 mode) |
| M.2 Storage | 1 x Blazing (Gen5x4), 2 x Hyper (Gen4x4) |
| SATA Ports | 4 x SATA3 6.0 Gb/s Connectors |
| USB Ports (Rear) | 2 x USB4 Type-C, 2 x USB 3.2 Gen2, 3 x USB 3.2 Gen1, 4 x USB 2.0 |
| Form Factor | ATX (30.5 cm x 24.4 cm), 8 Layer PCB |
| Model Name | Asrock X870 Steel Legend WiFi |
| Part Number | 90-MXBPJ0-A0UAYZ |
| UPC | N/A |
| EAN | 4710483949340 |
| Local Warranty | 3 Years Local Warranty |
What’s In The Box
Frequently Asked Questions
What is the technical benefit of the Steel Legend power design?
Notably, the motherboard technically facilitates a 14+2+1 Power Phase with 80A Dr.MOS. Specifically, it ensures consistent current delivery to the CPU VCore+SOC. Consequently, this protects your Ryzen 9000 processor from industrial-grade voltage ripple iterations.
Does the X870 Steel Legend support USB4 40Gbps?
Yes, the rear panel technically facilitates dual USB4 Type-C ports capable of 40 Gb/s excursions. Furthermore, these ports support PD 3.0 up to 15W charging. Therefore, you can execute elite-tier peripheral synchronization near-instantaneously.
