What is the key advantage of the FSP U580's back-connect support?

The FSP U580 supports back-connect motherboards (like ASUS BTF), moving all cable connections to the rear of the motherboard tray. This results in a cleaner, clutter-free interior view through the panoramic tempered glass panels.

How many fans are included with the FSP U580 case?

The U580 comes pre-installed with seven 120mm ARGB PWM fans (three side, three bottom, one rear), providing exceptional out-of-the-box cooling and customizable lighting effects.

What is the maximum radiator support for liquid cooling in the U580?

The case supports up to a 360mm radiator on the top, side, and bottom panels, allowing builders to create complex and efficient liquid cooling loops for demanding components.

تصفية

FSP U580 Panoramic TG Back-Connect Support With 7 120mm ARGB PWM Fans Black Ultra Mid Tower Case

FSP U580 Panoramic TG Back-Connect Support With 7 120mm ARGB PWM Fans Black Ultra Mid Tower Case

6499 EGP

Part Number (Model): U580-BA
Case Type: ATX Ultra Mid Tower
Motherboard Support: Back-Connect (BTF) Ready / ATX
Included Fans: 7x 120mm ARGB PWM Fans (Pre-installed)
Max GPU Length: 415mm
Max Radiator Support: Triple 360mm (Top, Side, and Bottom)
Warranty: 1 Year

متوفر في المخزون

Price Match Guarantee

رمز المنتج: 845685016089 التصنيف: CASES الوسوم: ULTRA, High Airflow, TG, PANORAMIC, U580-BA, MID TOWER CASE, MID, FSP, ARGB Fans, Back-Connect, 845685016089, ARGB, Pwm, fans, Black Case, U580, BLACK, With, Support, Panoramic Glass, FSP U580 series, TOWER, PWM Fans, back-connect support, 7 Fans, case, tempered glass, 120MM, 7 العلامة التجارية: FSP

FSP U580 Panoramic TG Back-Connect Support With 7 120mm ARGB PWM Fans Black Ultra Mid Tower Case

The FSP U580 Ultra Mid Tower Case redefines PC building with panoramic tempered glass, back-connect motherboard support, and seven pre-installed 120mm ARGB PWM fans for superior airflow and display.

7x 120mm

Pre-installed ARGB Fans

Back-Connect

Motherboard Support (BTF)

360mm

Triple Radiator Support

415mm

Max GPU Length

Clean Aesthetics and Optimized Airflow in the FSP U580 Ultra Mid Tower Case

Back-Connect Motherboard Ready

To begin with, the U580 is purpose-built to support modern back-connect (BTF) motherboards, relocating all power and I/O connections to the hidden rear compartment. Consequently, this innovative design eliminates front-facing cable clutter, providing an unmatched, clean view of your components through the three tempered glass panels (front, side, and bottom).

Pre-installed Fans and Superior Cooling

Furthermore, the case comes ready for intensive use with seven pre-installed 120mm ARGB PWM fans, ensuring high-efficiency airflow right out of the box. In addition, the spacious internal layout supports dual high-end graphics cards up to 415mm long and features full liquid cooling support, allowing up to a 360mm radiator installation on the top, side, and bottom panels simultaneously. Consequently, this ensures optimal thermal control for overclocked CPUs and powerful GPUs.

Technical Specifications for FSP U580 Ultra Mid Tower Case

Specification	Detail
Model Name / Part Number	U580-BA
UPC/EAN	845685016089 (UPC, Black)
Case Type	ATX Ultra Mid Tower
Motherboard Support	ATX (BTF/Back-Connect), M-ATX, Mini-ITX
Pre-installed Fans	7x 120mm ARGB PWM (3x Side Reverse, 3x Bottom Reverse, 1x Rear)
Max Radiator Support	360mm (Top, Side, and Bottom)
Max GPU Length	415mm (Supports Dual High-End Cards)
Max CPU Cooler Height	160mm
I/O Ports	Type-C, 2x USB 3.0, HD Audio
Material / Weight	0.7mm SPCC Steel, 3x Glass / 8.33 KG

💡 Pro Tip:

Since the FSP U580 comes with 7 pre-installed ARGB PWM fans, you can optimize your cooling configuration by setting the 3 bottom fans as intake and the 3 side fans and 1 rear fan as exhaust. This creates a balanced push-pull airflow path ideal for dissipating heat generated by high-end GPUs and CPUs.

Shop More From FSP

Explore All PC Cases

Important Notice: All information, specifications, and images provided herein are for reference and illustrative purposes only. Visual representations may not be perfectly accurate. Product specifications, features, and appearance can vary by model and country, and are subject to change without notice by the manufacturer. While we strive to present the most precise and comprehensive information, errors in typography or photography may occur.

For the most accurate and up-to-date details, we strongly recommend referring to the official manufacturer’s website. All trademarks and copyrights are the property of their respective owners.

If you have suggestions, or if you notice an error or incorrect information in this draft, please help us improve by reporting it directly via our feedback form: Alfrensia.com – Website Feedback & Report Form.

Case

MODEL	U580 Panoramic
CASE SIZE	MID TOWER
PANEL	Panoramic Glass, Tempered Glass
Motherboard Type	m-ATX, Mini ITX, ATX
FANS INCLUDED	7 FAN
Expansion Slots	9
Fan Support	2 x 140 mm, 10 x 120 mm
Radiator Support	240mm, 360mm
GPU Length	415mm
CPU Height	160 mm
PSU SUPPORT	240mm
Pre-installed PSU	Not Specified
I/O Ports	USB-C, HD Audio, 2x USB 3.0
3.5“ Drive Bays	1
2.5 Drive Bays	2-Bay Drive
Color	Black
Part Number	U580-BA
Warranty	1 Year
