MSI B840M Gaming Plus WIFI6E AM5 Motherboard
7500 جنيه
- Chipset: AMD B840
- CPU Socket: AM5
- CPU Support: AMD Ryzen™ 9000 / 8000 / 7000 Series
- Memory Support: 4x DDR5, Max 256GB, up to 8000+ (OC) MT/s
- Primary Expansion Slot: 1x PCIe 4.0 x16
- Storage: 2x M.2 (PCIe 4.0 x4), 4x SATA 6G
- Networking: Realtek® 2.5G LAN, Wi-Fi 6E & Bluetooth® 5.3
- Form Factor: mATX (243.84mm x 243.84mm)
- الضمان: 3 Years
MSI B840M Gaming Plus WIFI6E AM5 اللوحات الأم
The MSI B840M Gaming Plus Motherboard delivers next-gen performance for AM5 processors. To begin with, it features blazing-fast DDR5 memory support, PCIe 4.0, and built-in Wi-Fi 6E.
Official Product Page
Power Your Next Build with the MSI B840M Gaming Plus Motherboard
Next-Gen CPU & Memory Support
Built on the new AMD B840 chipset, this motherboard is ready for AMD Ryzen™ 9000, 8000, and 7000 series processors. Furthermore, it leverages the full power of DDR5 memory, supporting overclocking speeds up to 8000+ MT/s and AMD EXPO™ profiles for optimized performance.
Fast & Reliable Connectivity
This MSI B840M Gaming Plus Motherboard features a Realtek® 2.5G LAN port for high-speed wired connections. In addition, the pre-installed Wi-Fi 6E and Bluetooth® 5.3 module offers low-latency wireless gaming and seamless peripheral connectivity. Also, high-speed USB 10Gbps ports provide rapid data transfer.
MSI B840M Gaming Plus Motherboard Specifications
| Specification | Detail |
|---|---|
| Chipset | AMD B840 |
| سوكت المعالج | AM5 |
| CPU Support | Ryzen™ 9000 / 8000 / 7000 Series |
| Form Factor | mATX (243.84mm x 243.84mm) |
| Memory | 4x DDR5, up to 256GB, 8000+ (OC) MT/s |
| Expansion Slot | 1x PCIe 4.0 x16, 1x PCIe 3.0 x4 |
| وحدات التخزين | 2x M.2 (PCIe 4.0 x4), 4x SATA 6G |
| Networking | Realtek® 2.5G LAN |
| Wireless | Wi-Fi 6E & Bluetooth® 5.3 |
| Rear USB | 1x USB 10Gbps Type-C, 1x USB 10Gbps Type-A, 2x USB 5Gbps Type-A, 4x USB 2.0 |
💡 Pro Tip:
To unlock the full potential of your MSI B840M Gaming Plus Motherboard, install your DDR5 RAM in the recommended slots (A2 and B2 for a 2-stick kit). After that, boot into the BIOS and enable the AMD EXPO™ profile to instantly overclock your memory to its advertised 8000+ MT/s speed.
Important Notice: All information, specifications, and images provided herein are for reference and illustrative purposes only. Visual representations may not be perfectly accurate. Product specifications, features, and appearance can vary by model and country, and are subject to change without notice by the manufacturer. While we strive to present the most precise and comprehensive information, errors in typography or photography may occur.
For the most accurate and up-to-date details, we strongly recommend referring to the official manufacturer’s website. All trademarks and copyrights are the property of their respective owners.
If you have suggestions, or if you notice an error or incorrect information in this draft, please help us improve by reporting it directly via our feedback form: Alfrensia.com – Website Feedback & Report Form.
Copyright © 2025 alfrensia.com. All rights reserved.
| MODEL | |
|---|---|
| CHIPSET MANUFACTURERS | |
| سوكت المعالج | |
| شريحة اللوحة الأم | |
| Motherboard Type | |
| CPU SERIES | AMD Ryzen 7000 Series & Ryzen 8000 & Ryzen 9000 Series Processors |
| Technology | |
| Memory Speed | |
| Max Memory Size | |
| Memory Slot | |
| PCI-E X16 | |
| PCI-E GEN | PCIe 4.0 |
| PCI-E Slots (M.2) | |
| SATAIII | |
| Communication module | |
| Part Number | |
| الضمان |
