Msi Mag Z890 Tomahawk Wifi Motherboard

Msi Mag Z890 Tomahawk Wifi اللوحات الأم

Msi Mag Z890 Tomahawk Wifi اللوحات الأم

Chipset

• Manufacturer: INTEL
• Model: Z890

CPU Support

• Supports Intel® Core™ Ultra Processors (Series 2)
• Socket: LGA 1851

Memory

• 4x DDR5 UDIMM slots
• Maximum Memory Capacity: 256GB
• Supports 9200 – 6400 (OC) MT/s / 6400 – 4800 (JEDEC) MT/s
• Supports Memory Overclocking and Intel® XMP 3.0
• Supports Dual-Controller Dual-Channel mode
• Supports Non-ECC, Un-buffered memory
• Supports CUDIMM

Onboard Graphics

• 1x HDMI™ 2.1 with FRL (up to 4K 120Hz)
• 2x Thunderbolt™ 4 ports (up to 8K 60Hz)

وحدات التخزين

• 4x M.2 slots (PCIe 5.0 x4, PCIe 4.0 x4, SATA)
• 4x SATA 6G ports
• Supports RAID 0, 1, 5, 10 (SATA & M.2 NVMe)

Expansion Slots

• 3x PCI-E x16 slots (PCIe 5.0 x16, PCIe 4.0 x4)

Audio

• Realtek® ALC1220P Codec (7.1-Channel High Definition Audio)
• Supports S/PDIF output

Networking

• 2x Thunderbolt 4 ports (up to 40Gbps)
• Intel® Killer™ E5000 5Gbps LAN
• Intel® Killer™ BE1750x Wi-Fi 7 (pre-installed M.2 Key-E)
• Bluetooth® 5.4

USB Ports

• Rear Panel:
  • 4x USB 2.0
  • 4x USB 5Gbps Type-A
  • 3x USB 10Gbps Type-A
  • 1x USB 10Gbps Type-C
  • 2x Thunderbolt 4 40Gbps (Type-C)
• Front Panel:
  • 4x USB 2.0
  • 2x USB 5Gbps Type-A
  • 1x USB 20Gbps Type-C (supports USB PD 27W fast charging)

Other Features

• EZ Debug LED
• EZ Digit Debug LED
• TPM 2.0 support
• 4x Addressable V2 RGB LED connector

General

• Form Factor: ATX
• Operating System: Windows® 11 64-bit
