Apnx V1 White Mid Tower Case

Apnx V1 White Mid Tower Case

The Apnx V1 White Mid Tower Case redefines cooling dynamics and combines performance with a distinctive personality. This innovative mid-tower case integrates customizable cooling precision with a unique 45° angular intake design, all within a sleek, panoramic dual-chamber structure. Built for superior performance and an excellent user experience, the V1 offers optimized cooling options for both GPU and CPU, along with quick-release cooling brackets and panels for easy access. It further boasts a full tempered glass panoramic view and offers the unique choice of wood paneling for a refined touch, making it the perfect case for gamers, content creators, and PC builders seeking a blend of high performance and unique style.

Key Features of the APNX V1 White Mid Tower Case:

Redefined Cooling Dynamics with Unique Angular Intake:

The APNX V1 introduces an innovative thermal design within its dual-chamber panoramic case structure. This design features a unique 45° angular intake. Consequently, this significantly enhances overall airflow and thermal efficiency for both the GPU and CPU, all while preserving the hallmark full tempered glass view. The angular intake panel is highly versatile, supporting up to three 12cm, two 14cm, or two 16cm fans (maximum). Furthermore, the top mesh ventilation pattern visually highlights the distinct path of the internal airflow, intuitively demonstrating the improved cooling dynamics while simultaneously boosting top airflow. This thoughtful design ensures your components stay cool, even during intense gaming sessions or demanding workloads.

Versatile Motherboard and Cooling Configurations:

The V1 offers exceptional flexibility with its adjustable motherboard position mechanism. It provides two distinct motherboard installation positions, allowing you to optimize space. This can either grant more room for enhancing GPU airflow and cooling performance or facilitate the comfortable installation of thicker radiators and fans to prioritize CPU cooling. Additionally, you gain extensive control over your cooling setup. The case features ten fan slots in total, plus robust support for liquid coolers up to 360mm at the front-right, top, and bottom, and up to a 120mm radiator at the rear. For CPU cooling, it supports coolers up to 170mm in height. This wide array of configurations ensures you can tailor your cooling solution precisely to your needs.

Premium Craftsmanship and Easy Access:

The APNX V1 is a true statement of style, available in classic black, white, and various black/white mixed variants. Notably, it introduces APNX’s first-ever wood-accented panels, meticulously crafted from solid walnut or ash wood with a protective finish, allowing you to choose a look that perfectly complements your personal style. For ease of access, the top, front-angled, and both side panels are ingeniously designed to lock and snap without requiring tools or screws. Moreover, the V1 includes quick-release cooling brackets with minimal screws at the front-angled and bottom positions, ensuring hassle-free installation for any fans or radiators. This simplifies the building and maintenance process considerably.

Flexible Storage and Intuitive Cable Management:

The V1 provides redesigned, user-friendly, hinged storage brackets that facilitate a streamlined setup and the straightforward installation of multiple storage devices. It flexibly supports a maximum of 2 x 3.5” HDDs and 4 x 2.5” SSDs, or up to 6 x 2.5” SSDs, accommodating various storage needs. For heavy graphics cards (up to 395mm in length), a GPU mount with adjustable height and swivel angle is thoughtfully included, providing essential structural support. Additionally, the V1 is meticulously designed for intuitive cable management, featuring clear cable channels with included velcro ties and rubber pathways in the side panel. This ensures a super-clean appearance for your build, minimizing clutter. Hassle-free maintenance is also a priority, as the V1 includes removable filters on the bottom, side, and front-angled panels, plus a built-in top filter for effortless cleaning.

Explore compatible PC Cases or check other APNX Cases for more options. Find full details on the official APNX V1 product page.

Specifications of the APNX V1 White Mid Tower Case:

• Model: V1-WT-v1 (White variant)
• Case Type: Mid Tower
• Colors: Black, White, Black/White (White variant specified)
• Body Material: SGCC
• Front Panel Material: ABS
• Steel Thickness: 0.8mm
• Motherboards Support: ATX / Micro ATX / Mini-ITX
• Case Dimensions (Internal): 290 x 460 x 480mm (W x H x D)
• Case Dimensions (Overall): 290 x 485.5 x 500mm (W x H x D)
• 3.5” Drive Bays: 2 Max. (2 x 3.5”/2.5″)
• 2.5” Drive Bays: 6 Max. (4 x 2.5” and 2 x 2.5″/3.5”)
• Expansion Slots: 7
• GPU Clearance: Supports GPU up to 395mm (W/O radiator in the front-right position)
• CPU Cooler Clearance: Supports CPU cooler up to 170mm
• Air Cooling Support:
  • Front-Right: 120mm x 3 or 140mm x 2 or 160mm x 2 (Max.)
  • Top: 120mm x 3 or 140mm x 2 (Max.)
  • Bottom: 120mm x 3 (Max.) or 140mm x 2 (Max.)
  • Rear: 120mm x 1 (Max.)
• Liquid Cooling Support:
  • Front-Right: 120 / 140 / 240 / 280 / 360mm Radiator (Optional)
  • Top: 120 / 140 / 240 / 280 / 360mm Radiator (Optional)
  • Bottom: 120 / 140 / 240 / 280 / 360 Radiator (Optional) (140/280 Radiator: When M/B is at upper position; It’s not recommended to install a liquid cooling at the bottom.)
  • Rear: 120mm Radiator (Optional)
• Filters: Top (Built-in), Front-Right (Removable), Side (Removable), Bottom (Removable)
• I/O Ports: 1 x USB3.2 Gen 2×2 Type-C, 2 x USB3.2 Gen 1 Type-A, 1 x Audio & Mic.
• Internal Cable Management Depth: 90mm
• Power Supply: ATX PSU (Including cables, up to 220mm) (Optional)
• Model Number/SKU: APNX-V1 White
• EAN/UPC: 192275001964
