Gigabyte RTX 3080 10Gb Eagle OC Graphic Card

The GIGABYTE GeForce RTX 3080 EAGLE OC 10G is a PCIe 4.0 graphics card built on NVIDIA’s GeForce RTX 3080 GPU. It combines 10GB of GDDR6X memory with a triple-fan WINDFORCE cooling system for high-resolution gaming and GPU-accelerated workloads.

Key Features

• NVIDIA GeForce RTX 3080 GPU
• 10GB GDDR6X memory on a 320-bit interface
• 8,704 CUDA cores
• Factory core clock listed at 1755MHz
• PCIe 4.0 x16 interface
• WINDFORCE 3X cooling system with alternate-spinning fans
• Three DisplayPort 1.4a and two HDMI 2.1 outputs

Who Is It For?

For high-performance gaming and GPU-intensive applications. Check the power supply capacity, connectors, case clearance, and monitor inputs before choosing this card.

Compatibility & Setup

The card measures 320 × 128 × 56mm and lists a recommended 750W PSU with two 8-pin power connectors. Verify the power supply’s actual connectors and the case’s available GPU clearance before installation.

Technical Specifications

Frequently Asked Questions

How much PSU capacity is recommended?

750W is the listed recommendation; also check the PSU model, connector availability, and the rest of the system configuration.

Will it fit every PC case?

No. Confirm the 320mm card length, thickness, and slot clearance against the case specifications.

Which displays can connect?

The card has DisplayPort 1.4a and HDMI 2.1 outputs; select a cable and input compatible with your display.
