Msi PRO B550M P GEN3 DDR4 Motherboard
5500 EGP
- Supports AMD Ryzen™ 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen™ 5 3400G & Ryzen™ 3 3200G) and AMD Ryzen™ 4000 G-Series desktop processors
- Supports DDR4 Memory, up to 4400(OC) MHz
- Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
- Powerful Design: Core Boost, Digital PWM IC, DDR4 Boost
- Audio Boost: Reward your ears with studio grade sound quality
- Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength.
- MSI Center: A brand new software which integrates all MSI exclusive tools with user friendly user interface.
Views: 492
Out Of Stock.
SKU: 824142287521
Categories: AMD Motherboards, MOTHERBOARD
Tag: Msi PRO B550M P GEN3 DDR4 Motherboard
Msi PRO B550M P GEN3 DDR4 Motherboard
CPU
Supports AMD Ryzen™ 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen™ 5 3400G & Ryzen™ 3 3200G) and AMD Ryzen™ 4000 G-Series desktop processors
CHIPSET
AMD® B550 Chipset
MEMORY
- 4x DDR4 memory slots, supporting up to 128GB
- Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
- Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE
- 1DPC 1R max speed 4400 MHz
- 1DPC 2R max speed 3733 MHz
- 2DPC 1R max speed 3866 MHz
- 2DPC 2R max speed 3466 MHz
- Dual channel memory architecture
- Supports non-ECC UDIMM memory
- Supports ECC UDIMM memory (non-ECC mode)
- Supports un-buffered memory
EXPANSION SLOT
- 1x PCIe 3.0 x16 slot (From CPU)
- 2x PCIe 3.0 x1 slots (From AMD B550 chipset)
ONBOARD GRAPHICS
- 1x VGA port, supports a maximum resolution of 2048×1536 @50Hz, 2048×1280 @60Hz, 1920×1200 @60Hz
- 1x HDMI™ 1.4 port, supporting a maximum resolution of 4096×2160 @30Hz, 2560×1600 @60Hz
- 1x DVI-D port, supports a maximum resolution of 1920×1200 @60Hz
- Maximum shared memory of 16 GB
- Available only on processors featuring integrated graphics.
- Graphics specifications may vary depending on the CPU installed.
SATA PORTS
- 4x SATA 6Gb/s ports (From AMD B550 Chipset)
M.2 SSD SLOTS
- 1x M.2 slot (Key M)
- M2_1 slot (From CPU)
- Supports PCIe 3.0 x4
- Supports SATA 6Gb/s
- Supports 2242/ 2260/ 2280 storage devices
- M2_1 slot (From CPU)
RAID
- Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices
AUDIO
Realtek® ALC897 Codec
- 7.1-Channel High Definition Audio
LAN
- 1x Realtek® RTL8111H 1Gbps LAN controller
POWER CONNECTORS
- 1x 24-pin ATX main power connector
- 1x 8-pin ATX 12V power connector
INTERNAL USB CONNECTORS
- 1x USB 3.2 Gen 1 5Gbps connectors (From AMD B550 Chipset)
- Supports additional 2 USB 3.2 Gen 1 5Gbps ports
- 2x USB 2.0 Type-A connectors (From AMD B550 Chipset)
- Supports additional 4 USB 2.0 ports
FAN CONNECTORS
- 1x 4-pin CPU fan connector
- 2x 4-pin system fan connectors
SYSTEM CONNECTORS
- 1x Front panel audio connector
- 2x System panel connectors
- 1x Chassis Intrusion connector
- 1x Serial port connector
- 1x Parallel port connector
- 1x TPM module connector
JUMPERS
- 1x Clear CMOS jumper
LED FEATURES
- 1x 4-pin RGB LED connector
- 4x EZ Debug LED
BACK PANEL CONNECTORS
- Keyboard / Mouse
- VGA
- USB 2.0
- USB 3.2 Gen 1 5Gbps Type-A
- LAN port
- Audio connector
- USB 2.0
- DVI-D
- HDMI™
- USB 3.2 Gen 1 5Gbps Type-A
![ports](https://storage-asset.msi.com/global/picture/image/feature/mb/B550M/PRO-B550M-P-GEN3/io.png)
I/O CONTROLLER
NUVOTON NCT6795D-M Controller Chip
HARDWARE MONITOR
- CPU/ System/ Chipset temperature detection
- CPU/ System fan speed detection
- CPU/ System fan speed control
FORM FACTOR
- m-ATX Form Factor
- 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
BIOS FEATURES
- 1x 256 Mb flash
- UEFI AMI BIOS
- ACPI 6.1, SMBIOS 2.8
- Multi-language
SOFTWARE
- MSI Center
