Xpg Fusion 1600w 80 Plus Titanium ATX3.1 Digital Power Supply

Xpg Fusion 1600w 80 Plus Titanium ATX3.1 Digital Power Supply

The Xpg Fusion 1600w 80 Plus Titanium ATX3.1 Digital Power Supply is a high-performance, digitally controlled power supply designed for the most demanding PC builds. With an 80 Plus Titanium rating, it offers exceptional efficiency, minimizing energy waste and heat generation. Furthermore, its ATX 3.1 compatibility ensures readiness for next-generation components, providing stable and reliable power delivery.

Unmatched Efficiency and Robust Protection

This product features a Cybenetics Titanium rating, signifying top-tier efficiency and quiet operation, making it ideal for high-end systems where performance and acoustics are paramount. Specifically, it boasts comprehensive protection mechanisms including OCP (Over Current Protection), OVP (Over Voltage Protection), OPP (Over Power Protection), OTP (Over Temperature Protection), UVP (Under Voltage Protection), SCP (Short Circuit Protection), NLO (No Load Operation), and SIP (Surge & Inrush Protection), ensuring the safety of your components. Additionally, with a total output of up to 1600W and a power excursion capability of 3760W (up to 235% of rated power for 100μs), it can handle extreme power spikes from modern GPUs.

Moreover, the XPG Fusion 1600W PSU is equipped with a 135mm double ball bearing fan, ensuring effective cooling with a fan speed of 2700 ± 10% RPM and a long MTBF of 125,000 hours. It supports a wide range of input voltages (100-240V) and frequencies (47-63Hz) and comes with a full suite of connectors, including 2x 12V-2×6 / 12VHPWR (12+4) connectors for 600W, 10x PCI-E 6+2 Pin, and 12x SATA connectors, providing ample connectivity for multiple high-power components. Its robust certification list, including CE, CB, FCC, TUV, and more, guarantees compliance with global safety standards.

Explore compatible Power Supplies or check XPG Products for other options. Find full details on the official Xpg Fusion 1600w Power Supply product page.

Specifications

• Dimensions (L x W x H): 210 x 150 x 86mm
• Cybenetics Rating: TITANIUM
• 80 Plus Rating: TITANIUM
• ATX Version: ATX 3.0 & ATX 3.1
• Protections: OCP, OVP, OPP, OTP, UVP, SCP, NLO, SIP
• Certification: CE, CB, FCC (IC), TUV, cTUVus, TUV S-Mark, NOM, BSMI, UKCA, CQC, EAC
• PFC: > 0.99
• Input Voltage: 100-240V (15A | 8A) / 115-240V (15A | 8A)
• Input Frequency: 47-63Hz
• DC Output Voltage: +5V, +3.3V, +12V, -12V, +5Vsb
• Total Output: 1300W (100-115V) / 1600W (200-240V)
• Power Excursion: 3760W (*up to 235% of the PSU’s rated power for 100μs)
• Operating Temperature: 50°C
• Fan Size: 135 x 135 x 25mm
• Fan Bearing: Double Ball Bearing
• Fan Speed: 2700 ± 10% RPM
• MTBF: 125,000 hours @ 25°C
• ATX 24 Pin Connector: 1
• EPS 8 Pin Connector: 2
• PCI-E 6+2 Pin Connector: 10
• Molex 4 Pin Connector: 4
• 12V-2×6 / 12VHPWR (12+4) Connector (600W): 2
• SATA Connector: 12
• Floppy 4 Pin Connector: 1
• Weight: Product + cables: 2.5kg + 1.84kg (5.51lb+4.06lb) ±5%
• Warranty: 12 Years
• Model Number/SKU: FUSION1600T-BKCEU
• EAN/UPC: 842243027778
