ASUS ROG Astral GeForce RTX 5090 Edition 20 32GB GDDR7 Graphics Card
0 EGP
ROG Astral RTX 5090 Edition 20 with 32GB GDDR7, a curved AMOLED display, glass backplate and quad-fan cooling. Dimensions: 361 × 139.3 × 93.9mm; 4.7 slots; recommended PSU 1200W+.
Want to be notified when this product is back in stock?
The ASUS ROG Astral GeForce RTX 5090 Edition 20 32GB GDDR7 is a limited-edition graphics card celebrating ROG’s 20-year milestone, with a curved AMOLED display, transparent glass backplate and quad-fan cooling.
Key specifications
- GPU: NVIDIA GeForce RTX 5090; 21,760 CUDA cores
- Memory: 32GB GDDR7, 512-bit interface, 28Gbps
- Boost clock: 2730MHz default; 2760MHz OC mode
- Interface: PCI Express 5.0
- Cooling: quad-fan design, vapor chamber, heatpipes and liquid-metal GPU cooling
- Features: curved detachable AMOLED display and transparent glass backplate
- Dimensions: 361 × 139.3 × 93.9mm; 4.7-slot design
- Power: dual-input design up to 800W; 16-pin connector plus GC-HPWR gold finger; recommended PSU 1200W+
- Outputs: two HDMI 2.1b and three DisplayPort 2.1b
- Part number: ROG-ASTRAL-RTX5090-P32G-EDITION-20
Compatibility checklist
This is an exceptionally large 4.7-slot card. Confirm chassis clearance, motherboard compatibility with the hidden GC-HPWR/BTF connector, PSU capacity and power-cable routing before ordering. The USB Type-C connection powers the AMOLED display and does not carry video.
Contact Alfrensia to confirm current availability and local warranty coverage.
| MODEL | |
|---|---|
| CHIPSET MANUFACTURERS | |
| VGA SERIES | |
| VGA MEMORY SIZE | |
| Technology | |
| CORE CLOCKS | |
| Cuda Core | |
| Memory Bus | |
| Card Bus | |
| Recommended PSU | |
| Power Connectors | |
| DirectX | |
| I/O Ports | |
| GPU Length | |
| Part Number | |
| Warranty |
| GPU Dimensions | 361 × 139.3 × 93.9 mm |
|---|---|
| Slot Size | 4.7 slot |
| Cooling Design | Quad-fan cooling; vapor chamber; liquid-metal GPU thermal interface |
| Display Feature | Detachable curved AMOLED display; Type-C connection supplies display power only |
| Power Design | Dual power input up to 800W; 16-pin plus GC-HPWR gold finger |
| Accessories | Detachable AMOLED display; glass backplate; GC-HPWR adapter; card holder; Edition 20 accessories |
