Cooler Master MASTERBOX TD500 MESH V2 Black Mid Tower Case
4500 EGP
- Polygonal FineMesh Front Panel
- Three CF120 ARGB Fans Included
- USB 3.2 Gen 2 Type C Support
- Tool-Free Crystalline TG Side Panel
- PSU Shroud With Removable Cover
- ARGB Controller Included
- Removable Top Panel
- Removable HDD cage
Only 1 left in stock
| MODEL | |
|---|---|
| CASE SIZE | |
| PANEL | |
| Motherboard Tybe | |
| FANS ICLUDED | |
| Expansion Slots | |
| Fan Support | |
| Radiator Support | |
| GPU Length | |
| CPU Height | |
| PSU SUPPORT | |
| Pre-installed PSU | |
| I/O Ports | |
| 3.5“ Drive Bays | |
| 2.5" Drive Bays | |
| Color | |
| Part Number | |
| Warranty |
Cooler Master MASTERBOX TD500 MESH V2 Black Mid Tower Case
Cooler Master MASTERBOX TD500 MESH V2 Black Mid Tower Case
Materials – Exterior |
Steel, Mesh, Plastic |
Left Side Panel Material |
Tempered Glass |
Dimensions (L x W x H) |
499 x 210 x 500mm (Incl. Protrusions), 430 x 210 x 477mm (Excl. Protrusions) |
Volume |
50L |
Motherboard Support |
Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX* (*up to 12″ x 10.7″ motherboards, may impact cable management feature) |
Expansion Slots |
7 |
3.5″ Drive Bays |
2 |
2.5″ Drive Bays |
3 |
I/O Panel – USB Ports |
2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 Type C |
I/O Panel – Audio In / Out |
1x Audio Jack |
I/O Panel – Other |
1x ARGB Fan Hub |
Pre-installed Fans – Front |
3x 120mm CF120 ARGB |
Pre-installed Fans – Rear |
1x 120mm CF120 ARGB |
Fan Support – Top |
3x 120mm, 2x 140mm |
Fan Support – Front |
3x 120mm, 2x 140mm |
Fan Support – Rear |
1x 120mm |
Radiator Support – Top |
120mm, 140mm, 240mm, 280mm, 360mm (recommended maximum thickness -55mm) |
Radiator Support – Front |
120mm, 140mm, 240mm, 280mm, 360mm |
Radiator Support – Rear |
120mm |
Clearance – CPU Cooler |
165mm/6.49″ |
Clearance – PSU |
200mm, (Recommended up to 170mm) |
Clearance – GFX |
410mm / 16.14″ |
Cable Routing – Behind Motherboard Tray |
19mm / 0.74″ |
Dust Filters |
Front, Top, Bottom |
Power Supply Support |
Bottom Mount, ATX |
Series |
MasterBox Series |
Size |
Mid Tower |
- 3 x 120MM ARGB FANS – Pre-installed fan lighting can be assigned via onboard controller or directly connected to an ARGB supported motherboard (ASUS, Gigabyte, MSI & ASRock); The front and top panel features Fine Mesh technology for optimal airflow
- TEMPERED GLASS SIDE PANEL – A removable top panel and tempered-glass side panel provide easy access and showcase system build (tool-free design); The PSU shroud comes with a removable cover to showcase or hide the PSU
- MULTIPLE COOLING OPTIONS – Comes with 3 x CF120 ARGB frontal fans; The front & top panels each support up to 3 x 120mm fans/2 x 140mm fans, or a 360mm radiator, the rear panel supports 1 x 120mm fan/radiator
- MAXIMIZE THE POSSIBILITIES -The TD500 Mesh V2 interior accommodates E-ATX (up to 12” x 10.7”), ATX, micro-ATX and mini-ITX motherboards; CPU coolers up to 165mm in height; Graphics cards (GFX/GPU) up to 410mm in length; PSU up to 200mm in length
- RICH CONNECTIVITY I/O PANEL – The I/O panel features 2 x USB 3.2 Gen 1 Type-A ports, 1 x USB 3.2 Gen 2 Type-C port, 1 x audio jack and 1 x Reset/ARGB button for fast data transmission and excellent connectivity
