Corsair FRAME 5000D RS ARGB With 4x 140mm RS ARGB Fans Reverse Connector Support Black Mid Tower Case

Corsair FRAME 5000D RS ARGB With 4x 140mm RS ARGB Fans Reverse Connector Support Black Mid Tower Case

9999 EGP

Model Name: Corsair FRAME 5000D RS ARGB Mid-Tower PC Case
Part Number: CC-9011309-WW
InfiniRail Fan Mounting System: Sliding steel rail for flexible 120-200mm fan placement front/roof
Included Fans: 4× RS140 ARGB PWM fans with daisy-chain connections and magnetic dome bearings
Radiator Support: Triple 360mm mounting (top/front/side) + up to 14× 120mm fans total
RapidRoute 2.0 Cable Management: Pegboard tray with rotatable buckles and cable looms
Compatibility: Reverse connector motherboard support + GPU anti-sag arm + tempered glass panel
Warranty: 1 Year

In stock

Price Match Guarantee

SKU: 8400440491293 Category: CASES Tags: CORSAIR, RapidRoute 2.0, case, MID TOWER, ATX, 420mm radiator, tempered glass, gaming, RS, Modular, 5000D, High Airflow, CC-9011309-WW, FRAME, E-ATX, Reverse Connector, 8400440491293, ARGB, PC, FRAME 5000D, BLACK, USB 3.2, InfiniRail Brand: CORSAIR

Corsair FRAME 5000D RS ARGB With 4x 140mm RS ARGB Fans Reverse Connector Support Black Mid Tower Case

The Corsair FRAME 5000D RS ARGB Mid Tower Case facilitates exceptional thermal performance with modular customization and comprehensive reverse connector motherboard compatibility for modern high-end builds. Specifically engineered for professionals who demand superior airflow, organized cable management, and future-proof expandability, it bridges the gap between complexity and reliable performance.

140mm ARGB

420mm

Radiator

Fans Max

Local Warranty

Why the Corsair FRAME 5000D RS ARGB is the Elite Choice for Professionals

Revolutionary InfiniRail Fan Mounting System

The innovative steel multi-point mounting rail provides unmatched flexibility for front and roof fan configurations. Consequently, builders can slide the rail to mount fans up to 200mm (140mm in roof) exactly where needed, ensuring targeted airflow without the limitations of fixed mounting points that constrain traditional case designs.

Advanced RapidRoute 2.0 Cable Management

Furthermore, the upgraded pegboard motherboard tray features detachable and rotatable tie-down buckles with all-new cable looms for wrapping excess lengths. This system, combined with full reverse connector motherboard compatibility from ASUS, MSI, and Gigabyte, delivers completely hidden cabling for unobstructed airflow and professional aesthetics.

Comprehensive Technical Specifications

Feature	Detailed Specification
Model Name	Corsair FRAME 5000D RS ARGB With 4x 140mm RS ARGB Fans Reverse Connector Support Black Mid Tower Case
Model Number	CC-9011309-WW
Case Type	Mid-Tower ATX with modular FRAME system
Motherboard Support	Mini-ITX, Micro-ATX, ATX, E-ATX (305mm × 277mm)
Dimensions	542mm (H) × 556mm (L) × 250mm (W)
Weight	15.48 kg
Material	Steel, Tempered Glass, 3D-Y Airflow Steel, Plastic
Included Fans	4× RS140 ARGB PWM fans with daisy-chain connections
Fan Support – Front	3× 120mm, 3× 140mm, 2× 200mm
Fan Support – Top	3× 120mm, 3× 140mm
Fan Support – Side	3× 120mm, 3× 140mm
Fan Support – Bottom	4× 120mm
Fan Support – Rear	1× 140mm, 1× 120mm
Maximum Fans	Up to 14× 120mm fans simultaneously
Radiator Support – Top	420mm, 360mm, 280mm, 240mm
Radiator Support – Front	360mm, 280mm, 240mm
Radiator Support – Side	360mm, 280mm, 240mm
Radiator Support – Rear	140mm, 120mm
Maximum CPU Cooler Height	175mm
Maximum GPU Length	450mm
Drive Bays	2× 3.5″ internal, 6× 2.5″ internal
Expansion Slots	8 Horizontal or 3 Vertical (riser card sold separately)
Front I/O	1× USB 3.2 Gen 2 Type-C, 4× USB 3.2 Gen 1 Type-A, 1× Audio combo jack
Special Features	InfiniRail fan mounting, RapidRoute 2.0 cable management, GPU anti-sag stabilization arm, reverse connector motherboard support, ARGB light strip, cable shroud
Cable Routing Space	42mm behind motherboard tray
Side Panels	Left: Tempered Glass, Right: Steel
Dust Filtration	Yes (multiple filter locations)
Warranty	1 Year Limited Warranty

FAQ

Which reverse connector motherboards are compatible with this case?

The FRAME 5000D RS ARGB is fully compatible with reverse connector motherboards from ASUS (BTF series), MSI (Project Zero), and Gigabyte (Project Stealth). Since all power connectors are located on the back of these motherboards, the case’s 42mm cable routing space and RapidRoute 2.0 system ensure completely hidden cabling for superior airflow and clean aesthetics.

Can I install a 420mm AIO radiator in this case?

Yes. The top mounting location supports radiators up to 420mm, while front and side positions accommodate up to 360mm. Additionally, the InfiniRail system allows precise positioning of fans and radiators without being constrained by fixed mounting holes, enabling optimal cooling configuration for high-performance builds with multiple radiators.

Help us improve our product data accuracy. If you notice any error in this draft, please report it via our official feedback form:
Alfrensia.com – Website Feedback & Report Form.

Case

MODEL	FRAME 5000D RS ARGB
CASE SIZE	MID TOWER
PANEL	Tempered Glass
Motherboard Type	E-ATX, Mini ITX, Micro ATX, ATX
FANS INCLUDED	4 FAN
Expansion Slots	3 Vertical, 8 Horizontal
Fan Support	2x 200mm, 10x 120mm, 10x 140mm
Radiator Support	120mm, 140mm, 240mm, 280mm, 360mm, 420mm
GPU Length	450 mm
CPU Height	175 mm
PSU SUPPORT	ATX
Pre-installed PSU	Not Specified
I/O Ports	USB 3.2 Gen 2 Type-C, Audio In & Out, 4x USB 3.2 Gen 1 Type-A
3.5“ Drive Bays	2
2.5 Drive Bays	6-Bay Drive
Color	Black
Part Number	CC-9011309-WW
Warranty	1 Year
