Lian Li Odyssey X Silver Full Tower Gaming Case

Name: Lian Li Odyssey X Silver Full Tower Gaming Case
Brand: LIAN LI
SKU: TR-01A
Availability: OutOfStock

24999 EGP

Out Of Stock.

Price Match Guarantee

In stock

On sale (24)

PRODUCT NAME	LIAN LI ODYSSEY X
MODEL	TR-01A
COLOR	Silver
DIMENSIONS	DIMENSIONS Dynamic/Dynamic-R (Rotate) (D) 575.5mm x (W) 234mm x (H) 558.5mm Performance (D) 537.1mm x (W) 368.6mm x (H) 596.7mm
MATERIALS	Aluminum Steel 4.0mm Black tempered glass (both sides)
MOTHERBOARD SUPPORT	EEB/E-ATX/ATX/Micro-ATX/Mini-ITX
FAN SUPPORT	Dynamic Front：3 x 120mm or 2 x 140mm Top：3 x 120mm or 2 x 140mm Side：3 x 120mm or 2 x 140mm Dynamic-R (Rotate) Front：3 x 120mm or 2 x 140mm Base：4 x 120mm or 3 x 140mm Performance Front：4 x 120mm or 3 x 140mm Top：3 x 120mm or 2 x 140mm RADIATOR SUPPORT Dynamic Front：1 x 360/280/240mm Side：1 x 360/280/240mm Dynamic-R (Rotate) Front：1 x 360/280/240mm Base：1 x 480/420/360/280/240mm Performance Front：1 x 480/420/360/280/240mm Top：1 x 360/280/240mm
PSU SUPPORT LENGTH	Max 280mm
GPU LENGTH CLEARANCE	Max 423mm
CPU COOLER HEIGHT CLEARANCE	Max 167mm
DRIVE	3 X 3.5″ HDD or 3 X 2.5″ SSD
EXPANSION SLOT	8
I/O PORTS	2 X USB 3.0, 1 X USB 3.1 TYPE-C, 1 X HD AUDIO
WARRANTY	1 year

Designed to give you unobstructed airflow for enhanced thermal controls, this configuration supports a wide range of cooling options with multi-radiator support. Easily install 480mm and 280mm or dual 360mm radiators, giving you ample room for CPU and GPU liquid AiO coolers. An included adjustable water pump mounting bracket converts from the front I/O mounting bracket to allow the installation of tall water pumps used in custom liquid cooling loops. You can also install up to three 120mm or two 140mm fans on the top bracket, and four 120mm or three 140mm fans on the front bracket for enhanced airflow.

Dynamic mode provides you with the standard configuration, allowing you to install two 360mm radiators as well as small and medium liquid cooling tanks for custom loops. Install three 120mm or two 140mm fans on the top bracket, three 120mm or two 140mm fans on the front bracket, and up to three 120mm or 140mm fans on the side panel.

Dynamic-R (Rotate) mode allows you to change the orientation of your build and relocate your back I/O ports to the top of your system for convenient access while maintaining proper cooling. Install 480mm and 280mm or dual 360mm radiators for CPU and GPU liquid AiO cooling. Install up to three 120mm or two 140mm fans to the front bracket, and up to four 120mm or three 140mm fans to the bottom bracket.

No matter the configuration of your rig, the ODYSSEY X allows you to manage cables easily with various fixtures and rubber grommets providing a safe and secure hold. The Dynamic mode cover is converted into a cable cover in Performance mode for an added style.

The front I/O panel uses a modular design, allowing you adjust the direction and orientation of your ports depending on the configuration. You get Two USB 3.2 Gen 1 Type-A ports, one USB 3.2 Gen 1 Type-C port, 3.5mm audio input, and a 3.5mm audio output, giving you ample connectivity for your peripherals.

The flexible layout of the ODYSSEY X gives you enough room to fit larger graphics cards up to 16.6 inches long. You also get support for power supplies up to 11 inches long, giving you enough room to manage your PSU and cables.

Lian Li consulted with the world-renowned German overclocking, water cooling, and gaming enthusiast, der8auer, to ensure the case could withstand standard and advance settings. A unique der8auer and Lian Li logo badge is included, allowing you to place this plate anywhere on the case.

You can show-off your graphics card with optional vertical mounting hardware from Lian Li, giving your rig a truly unique look.
