Platform

Desktop

Product Family

AMD Ryzen™ Processors

Product Line

AMD Ryzen™ 7 8000 G-Series Desktop Processors with Radeon™ Graphics

AMD PRO Technologies

No

Consumer Use

Yes

Regional Availability

Global

Former Codename

“Phoenix”

Architecture

“Zen 4”

# of CPU Cores

8

Multithreading (SMT)

Yes

# of Threads

16

Max. Boost Clock

Up to 5.1GHz

Base Clock

4.2GHz

L2 Cache

8MB

L3 Cache

16MB

Default TDP

65W

AMD Configurable TDP (cTDP)

45-65W

Processor Technology for CPU Cores

TSMC 4nm FinFET

CPU Compute Die (CCD) Size

178mm²

Package Die Count

1

Unlocked for Overclocking

Yes

AMD EXPO™ Memory Overclocking Technology

Yes

Precision Boost Overdrive

Yes

Curve Optimizer Voltage Offsets

Yes

AMD Ryzen™ Master Support

Yes

CPU Socket

AM5

CPU Boost Technology

Precision Boost 2

Instruction Set

x86-64

Supported Extensions

AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64

Max. Operating Temperature (Tjmax)

95°C

Launch Date

1/31/2024

OS Support

Windows 11 – 64-Bit Edition, Windows 10 – 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit (OS support may vary by manufacturer)

Connectivity

Native USB 4 (40Gbps) Ports

2

Native USB 3.2 Gen 2 (10Gbps) Ports

2

Native USB 2.0 (480Mbps) Ports

1

PCIe Version

PCIe 4.0

Native PCIe Lanes (Total/Usable)

20 / 16

NVMe Support

Boot, RAID0, RAID1

System Memory Type

DDR5

Memory Channels

2

Max. Memory

256GB

System Memory Subtype

UDIMM

Max Memory Speed

Graphics Capabilities

Integrated Graphics

Yes

Graphics Model

AMD Radeon™ 780M

Graphics Core Count

12

Graphics Frequency

2900 MHz

DirectX Version

12

DisplayPort Version

2.1

DisplayPort Extensions

HDR Metadata, Adaptive-Sync, UHBR10

DisplayPort Max Refresh Rates (SDR)

7680×4320 @ 60Hz, 3840×2160 @ 240Hz, 3440×1440 @ 360Hz, 2560×1440 @ 480Hz, 1920×1080 @ 600Hz

DisplayPort Max Refresh Rates (HDR)

7680×4320 @ 60Hz, 3840×2160 @ 240Hz, 3440×1440 @ 360Hz, 2560×1440 @ 480Hz, 1920×1080 @ 600Hz

HDMI Version

2.1

HDCP Version Supported

2.3

USB Type-C DisplayPort Alternate Mode

Yes

Multi-Monitor Support

Yes

Max Displays

4

AMD FreeSync™

Yes

Wireless Display

Miracast
