Asus Rog Strix B760 I Gaming Wifi Motherboard

Asus Rog Strix B760 I Gaming Wifi Motherboard

Experience powerhouse performance in a compact package with the ROG STRIX B760-I GAMING WIFI motherboard. Designed for Small Form Factor (SFF) enthusiasts who refuse to compromise, this Mini-ITX board leverages the Intel® B760 chipset to support 14th, 13th, and 12th Gen Intel® Core™ processors. It packs cutting-edge features like DDR5 memory support up to 7600MHz (OC), a future-proof PCIe 5.0 x16 slot, and integrated Wi-Fi 6E, making it the ideal foundation for a high-performance, space-saving gaming rig or workstation.

Discover Compact Power and Connectivity

The ROG STRIX B760-I GAMING WIFI punches well above its weight class. Its PCIe 5.0 x16 slot offers double the bandwidth of PCIe 4.0, ready for next-generation graphics cards. Unlock blazing-fast memory speeds with support for up to 96GB of DDR5 RAM, enhanced by ASUS OptiMem II technology for improved signal integrity and overclocking potential. Furthermore, the board features robust power delivery with Extreme Engine Digi+ and ProCool connectors, ensuring stable performance even under demanding loads.

Cooling is handled effectively with an M.2 heatsink and backplate, keeping your high-speed NVMe drives running optimally. Connectivity is paramount, featuring onboard Intel® 2.5Gb Ethernet and the latest Wi-Fi 6E for ultra-low latency networking. For immersive audio, the ROG SupremeFX S1220A CODEC, paired with a Savitech SV3H712 amplifier, delivers pristine 7.1-channel high-definition sound. Additionally, a comprehensive array of USB ports, including a rear USB 3.2 Gen 2×2 Type-C® port and front-panel USB 3.2 Gen 2 Type-C® connector, ensures you can connect all your peripherals. ASUS Q-Design features like M.2 Q-Latch and Q-DIMM simplify the building process, making this Mini-ITX board surprisingly user-friendly. Explore compatible processors and memory kits to complete your build. For more details, visit the official ASUS product page.

Specifications

• Model: ROG STRIX B760-I GAMING WIFI
• Part Number: 90MB1D90-M1EAY0
• EAN: 391107995304
• Focus Keyphrase: ROG STRIX B760-I GAMING WIFI
• CPU Socket: Intel® Socket LGA1700 for 14th, 13th & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
• Chipset: Intel® B760
• Memory: 2 x DIMM, Max. 96GB, DDR5 7600+(OC) / 5600 / … / 4800 MHz Non-ECC, Un-buffered Memory, Dual Channel, Intel® XMP, OptiMem II
• Graphics Output: 1 x DisplayPort 1.4 (4K@60Hz), 1 x HDMI® 2.1 (4K@60Hz)
• Expansion Slots: 1 x PCIe 5.0 x16 slot
• Storage: 2 x M.2 slots (PCIe 4.0 x4), 4 x SATA 6Gb/s ports (Supports Intel® Rapid Storage Technology RAID 0/1/5/10)
• Ethernet: 1 x Intel® 2.5Gb Ethernet (ASUS LANGuard)
• Wireless: Wi-Fi 6E (802.11ax, 2×2, 2.4/5/6GHz), Bluetooth® v5.3
• Audio: ROG SupremeFX 7.1-Channel High Definition Audio CODEC S1220A, Savitech SV3H712 AMP
• USB (Rear): 1x USB 3.2 Gen 2×2 (Type-C®), 4x USB 3.2 Gen 1 (3x Type-A, 1x Type-C®), 3x USB 2.0 (Type-A)
• USB (Front): 1x USB 3.2 Gen 2 connector (Type-C®), 1x USB 3.2 Gen 1 header (2 ports), 1x USB 2.0 header (2 ports)
• Form Factor: Mini-ITX (17 cm x 17 cm)
• Special Features: Extreme Engine Digi+, Q-Design (M.2 Q-Latch, Q-DIMM, Q-LED, Q-Slot), M.2 Heatsink/Backplate, EZ DIY (ProCool, Pre-mounted I/O shield, SafeSlot, SafeDIMM), AURA Sync

Q&A

Target Audience

This motherboard is primarily aimed at gamers, enthusiasts, and power users constructing high-performance Small Form Factor (SFF) PCs where space is limited, but cutting-edge features and performance are essential.

Key Reasons to Choose

Opt for the ROG STRIX B760-I GAMING WIFI for its potent combination of Mini-ITX compactness, next-gen PCIe 5.0 readiness, high-speed DDR5 support, advanced networking (2.5Gb LAN + Wi-Fi 6E), premium ROG SupremeFX audio, and robust power delivery suitable for top-tier Intel processors.

What are the Pros?

• Compact Mini-ITX form factor fits in small cases.
• Future-proof PCIe 5.0 x16 slot for graphics cards.
• Supports high-speed DDR5 memory up to 7600MHz (OC) and 96GB capacity.
• Excellent connectivity: Intel 2.5Gb Ethernet, Wi-Fi 6E, Bluetooth 5.3.
• Premium ROG SupremeFX S1220A audio with Savitech amplifier.
• Robust power delivery and VRM design (Extreme Engine Digi+).
• Effective M.2 cooling solution with heatsink and backplate.
• Comprehensive USB options including rear USB 3.2 Gen 2×2 Type-C.
• User-friendly Q-Design features simplify building.

What are the Cons?

• Limited expansion capabilities inherent to the Mini-ITX form factor (only one PCIe slot).
• Only two DIMM slots for memory.
• Typically carries a premium price compared to larger ATX B760 boards.

Verdict

Overall, the ROG STRIX B760-I GAMING WIFI stands out as a feature-packed powerhouse squeezed into a Mini-ITX footprint. It delivers exceptional performance potential for 12th, 13th, and 14th Gen Intel CPUs, coupled with next-generation connectivity and expansion options like PCIe 5.0 and DDR5. If you’re building a compact gaming PC or workstation without sacrificing performance or high-end features, this motherboard is a superb, albeit premium, choice. It’s the ideal core for an uncompromising SFF build.
