Cooler Master Elite V4 600 600W 80+ White Tray Power Supply
1930 EGP
- Active PFC + Forward Topology Design
- High Temperature Resistance
- Peak Power Tolerance
- 80 Plus White EU 230V Efficiency
- Durable, Reliable, And Safe
Views: 715
Out Of Stock.
SKU: 884102056642
Category: POWER SUPPLY
Tags: 600W, 600W 80+ White Tray Power Supply, 80+ White, COOLER MASTER, Elite V4 600, POWER, POWER SUPPLY, Supply, TRAy, Tray Power Supply
Cooler Master Elite V4 600 600W 80+ White Tray Power Supply
-
Model
- MPE-6001-ACABN
-
ATX Version
- ATX 12V Ver. 2.41
-
PFC
- Active PFC
-
Input Voltage
- 200-240Vac
-
Input Current
- 5A
-
Input Frequency
- 50-60Hz
-
Dimensions (L x W x H)
- 140 x 150 x 86 mm
-
Fan Size
- 120mm
-
Fan Bearing
- Sleeve Bearing
-
Efficiency
- 85% @ Typical Load
-
80 PLUS Rating
- 80 PLUS Standard 230V EU
-
ErP 2014 Lot 3
- Yes
-
Operating Temperature
- 40°C
-
Power Good Signal
- 100 – 500 ms
-
Hold Up Time
- >14ms at 100% load
-
MTBF
- >100,000 Hours
-
Protections
- OVP, OPP, OTP, SCP, UVP
-
Regulatory
- TUV, cTUVus, CE, BSMI, FCC, EAC, RCM, KCC, CCC, CB
-
MB 24 Pin Connectors
- 1
-
EPS 4+4 Pin Connectors
- 1
-
SATA Connectors
- 5
-
Peripheral 4 Pin Connectors
- 3
-
PCI-e 6+2 Pin Connectors
- 2
-
Series
- Elite Series
-
80 Plus
- Standard
-
Modular
- Non Modular
-
Wattage
- 600W
Cooler Master Elite V4 600 600W 80+ White Tray Power Supply
