Cooler Master MASTERBOX TD500 MESH V2 White Mid Tower Case

Name: Cooler Master MASTERBOX TD500 MESH V2 White Mid Tower Case
Brand: COOLER MASTER
SKU: 884102107672
Availability: OutOfStock

4700 EGP

Out Of Stock.

Price Match Guarantee

Materials – Exterior	Steel, Mesh, Plastic
Left Side Panel Material	Tempered Glass
Dimensions (L x W x H)	499 x 210 x 500mm (Incl. Protrusions), 430 x 210 x 477mm (Excl. Protrusions)
Volume	50L
Motherboard Support	*Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX (up to 12″ x 10.7″ motherboards, may impact cable management feature)*
Expansion Slots	7
3.5″ Drive Bays	2
2.5″ Drive Bays	3
I/O Panel – USB Ports	2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 Type C
I/O Panel – Audio In / Out	1x Audio Jack
I/O Panel – Other	1x ARGB Fan Hub
Pre-installed Fans – Front	3x 120mm CF120 ARGB
Pre-installed Fans – Rear	1x 120mm CF120 ARGB
Fan Support – Top	3x 120mm, 2x 140mm
Fan Support – Front	3x 120mm, 2x 140mm
Fan Support – Rear	1x 120mm
Radiator Support – Top	120mm, 140mm, 240mm, 280mm, 360mm (recommended maximum thickness -55mm)
Radiator Support – Front	120mm, 140mm, 240mm, 280mm, 360mm
Radiator Support – Rear	120mm
Clearance – CPU Cooler	165mm/6.49″
Clearance – PSU	200mm, (Recommended up to 170mm)
Clearance – GFX	410mm / 16.14″
Cable Routing – Behind Motherboard Tray	19mm / 0.74″
Dust Filters	Front, Top, Bottom
Power Supply Support	Bottom Mount, ATX

Series	MasterBox Series
Size	Mid Tower

3 x 120MM ARGB FANS – Pre-installed fan lighting can be assigned via onboard controller or directly connected to an ARGB supported motherboard (ASUS, Gigabyte, MSI & ASRock); The front and top panel features Fine Mesh technology for optimal airflow
TEMPERED GLASS SIDE PANEL – A removable top panel and tempered-glass side panel provide easy access and showcase system build (tool-free design); The PSU shroud comes with a removable cover to showcase or hide the PSU
MULTIPLE COOLING OPTIONS – Comes with 3 x CF120 ARGB frontal fans; The front & top panels each support up to 3 x 120mm fans/2 x 140mm fans, or a 360mm radiator, the rear panel supports 1 x 120mm fan/radiator
MAXIMIZE THE POSSIBILITIES -The TD500 Mesh V2 interior accommodates E-ATX (up to 12” x 10.7”), ATX, micro-ATX and mini-ITX motherboards; CPU coolers up to 165mm in height; Graphics cards (GFX/GPU) up to 410mm in length; PSU up to 200mm in length
RICH CONNECTIVITY I/O PANEL – The I/O panel features 2 x USB 3.2 Gen 1 Type-A ports, 1 x USB 3.2 Gen 2 Type-C port, 1 x audio jack and 1 x Reset/ARGB button for fast data transmission and excellent connectivity

Case

MODEL	MASTERBOX TD500 MESH V2
CASE SIZE	MID TOWER
PANEL	Airflow, Tempered Glass
Motherboard Type	Micro ATX, ATX, SSI CEB, E-ATX, Mini ITX
FANS INCLUDED	3 FAN
Expansion Slots	7
Fan Support	7 x 120 mm
Radiator Support	360mm
GPU Length	410mm
CPU Height	165 mm
PSU SUPPORT	200 mm
Pre-installed PSU	N/A
I/O Ports	USB 3.2 Gen 2 Type C, 2x USB 3.2 Gen 1
3.5“ Drive Bays	2
2.5 Drive Bays	3-Bay Drive
Color	White
Part Number	TD500V2-WGNN-S00
Warranty	1 Year
