Gigabyte Z890 UD Wifi 6E UD LGA1851 Motherboard

Gigabyte Z890 UD Wifi 6E UD LGA1851 Motherboard:

The Gigabyte Z890 UD Wifi 6E UD LGA1851 Motherboard is engineered for extreme performance and future-ready connectivity for Intel® Core™ Ultra Processors. This Gigabyte Z890 UD WIFI6E motherboard features a Digital Twin 12+1+2 Phases VRM solution. It supports DDR5 memory up to 9200(O.C) MT/s. Furthermore, with PCIe 5.0 x16 slots and Wi-Fi 6E connectivity, this LGA1851 motherboard delivers blazing-fast speeds and exceptional stability for demanding tasks and next-gen gaming.

Infinite Memory Performance and Durable Power Design with the Gigabyte Z890 UD WIFI6E Motherboard:

This Gigabyte Z890 UD WIFI6E motherboard boosts DDR5 memory performance. It offers top-notch compatibility using various advanced methods, including D5 Bionic Corsa. It supports up to 256 GB of system memory across four DDR5 DIMM sockets. This ensures ample capacity for demanding applications. The Digital Twin 12+1+2 Phases VRM solution with 60A DrMOS delivers incredibly stable and clean power to your CPU. This is crucial for overclocking and sustained high performance. The 2X Copper PCB further enhances thermal performance and signal integrity.

The Z890 UD WIFI6E is built with GIGABYTE Ultra Durable™ components. These provide prime performance and a timeless platform. AI-Powered Gaming PC features like AI Perfdrive and AORUS AI Snatch (coming soon) offer optimal and customized BIOS preset profiles for users. AI-Driven PCB Design and HyperTune BIOS further optimize performance. This ensures this LGA1851 motherboard is ready for the future of computing.

Ultrafast Connectivity and Comprehensive Thermal Design for the Gigabyte Z890 UD WIFI6E Motherboard:

This Gigabyte Z890 UD WIFI6E motherboard offers ultimate connectivity. It includes a PCIe 5.0 x16 slot and three M.2 slots (one PCIe 5.0 x4, two PCIe 4.0 x4). This provides blazing-fast data-transfer speeds for the latest GPUs and NVMe SSDs. Realtek 2.5GbE LAN and Intel® Wi-Fi 6E AX211 (or Realtek® Wi-Fi 6E RTL8852CE) ensure gigabit wireless performance. Bluetooth 5.3 is also supported.

The comprehensive thermal design includes VRM Thermal Armor Advanced and M.2 Thermal Guard. These keep your system cool and efficient. Extensive USB connectivity includes a USB4® USB Type-C® port on the back panel (with DisplayPort video outputs), a front USB Type-C® with USB 3.2 Gen 1 support, and multiple USB 3.2 Gen 2, Gen 1, and USB 2.0/1.1 ports. Display outputs include USB4® USB Type-C® and DisplayPort 2.1. This supports resolutions up to 3840×2160@144 Hz.

Explore compatible Intel Motherboards or other Motherboard options. You will also need a compatible Intel Processor (LGA1851 socket) and DDR5 RAM. Check Gigabyte Products for more options. Find full details on the official Gigabyte Z890 UD Wifi 6E Motherboard product page.

Specifications:

• CPU Socket: LGA1851 (Support for Intel® Core™ Ultra Processors)
• Chipset: Intel® Z890 Express Chipset
• Memory: 4 x DDR5 DIMM sockets, Max. 256 GB, Dual Channel, up to 9200(O.C) MT/s
• Onboard Graphics: Integrated Graphics Processor-Intel® HD Graphics support (via USB4® USB Type-C® and DisplayPort 2.1)
• Audio: Realtek® Audio CODEC, 7.1-channel, S/PDIF Out support
• LAN: Realtek® 2.5GbE LAN chip
• Wireless Communication: Intel® Wi-Fi 6E AX211 (or Realtek® Wi-Fi 6E RTL8852CE), BLUETOOTH 5.3
• Expansion Slots (CPU): 1 x PCI Express x16 slot (PCIe 5.0, x16 mode)
• Expansion Slots (Chipset): 2 x PCI Express x16 slots (PCIe 4.0, x4 mode), 1 x PCI Express x16 slot (PCIe 4.0, x1 mode)
• Storage Interface (CPU): 1 x M.2 connector (PCIe 5.0 x4/x2), 1 x M.2 connector (PCIe 4.0 x4/x2)
• Storage Interface (Chipset): 1 x M.2 connector (SATA and PCIe 4.0 x4/x2), 4 x SATA 6Gb/s connectors
• RAID Support: RAID 0, 1, 5, 10 for NVMe SSD and SATA storage devices
• USB (CPU): 1 x USB4® USB Type-C® port (back panel)
• USB (Chipset): 1 x USB Type-C® (USB 3.2 Gen 1, internal header), 1 x USB 3.2 Gen 2 Type-A (red, back panel), 6 x USB 3.2 Gen 1 (4 back panel, 2 internal header)
• USB (Chipset+2 USB 2.0 Hubs): 8 x USB 2.0/1.1 ports (4 back panel, 4 internal headers)
• Back Panel Connectors: 4 x USB 2.0/1.1, 1 x PS/2, 1 x DisplayPort, 4 x USB 3.2 Gen 1, 1 x USB4® USB Type-C®, 1 x USB 3.2 Gen 2 Type-A, 1 x RJ-45, 2 x SMA antenna, 3 x audio jacks, Q-Flash Plus button
• Form Factor: ATX Form Factor; 30.5cm x 24.4cm
• Operating System: Support for Windows 11 64-bit
• Model Number/SKU: 9MZ89UW6-00-G10
• EAN/UPC: 889523045336
