Msi Pro Z890 P Wifi Motherboard
13700 EGP
- Model: Pro Z890 P
- CPU Series: Core Ultra (Series 2)
- Memory Slot: 4
- PCI-E X16: 3
- PCI-E Slots (M.2): 4
- SATAIII: 4x SATA 6.0 Gb/s
- Communication module: Bluetooth, Wireless
- Part Number: 911-7E34-001
- Warranty: 3 year
Out Of Stock.
Msi Pro Z890 P Wifi Motherboard
Msi Pro Z890 P Wifi Motherboard
General
- Chipset: INTEL Z890
- Socket: LGA 1851
- Form Factor: ATX (243.84mm x 304.8mm)
- Operating System: Windows® 11 64-bit
CPU Support
- Supports Intel® Core™ Ultra Processors (Series 12)
Memory
- 4x DDR5 UDIMM slots
- Maximum Memory Capacity: 256GB
- Supports 9200 – 6400 (OC) MT/s / 6400 – 4800 (JEDEC) MT/s
- Supports Memory Overclocking and Intel® XMP 3.0
- Supports Dual-Controller Dual-Channel mode
- Supports Non-ECC, Un-buffered memory
- Supports CUDIMM
Storage
- 4x M.2 slots (PCIe 5.0 x4, PCIe 4.0 x4, SATA)
- 4x SATA 6G ports
- Supports RAID 0, 1, 5, 10 (SATA & M.2 NVMe)
Onboard Graphics
- 1x HDMI 2.1 (up to 4K 60Hz)
- 1x DisplayPort 1.4 (up to 4K 60Hz)
- 1x Thunderbolt 4 (up to 8K display)
Expansion Slots
- 3x PCI-E x16 slots (PCIe 5.0 x16, PCIe 4.0 x4)
- 1x PCI-E x1 slot (PCIe 4.0)
Networking
- Realtek® ALC897 Codec (7.1-Channel High Definition Audio)
- Realtek® 8126 5Gbps LAN
- Intel® Wi-Fi 7 (pre-installed M.2 Key-E)
- Bluetooth® 5.4
USB Ports
- Rear Panel:
- 4x USB 2.0
- 2x USB 5Gbps Type-A
- 1x USB 10Gbps Type-A
- 1x USB 10Gbps Type-C
- 1x Thunderbolt 4 40Gbps (Type-C)
- Front Panel:
- 4x USB 2.0
- 4x USB 5Gbps Type-A
- 1x USB 20Gbps Type-C
Other Features
- EZ Debug LED
- 4x EZ Conn-header
- 3x Addressable V2 RGB LED connector
- TPM 2.0 support
MOTHERBOARD
| MODEL | |
|---|---|
| CHIPSET MANUFACTURERS | |
| CPU Socket | |
| Motherboard Chipset | |
| Motherboard Type | |
| CPU SERIES | |
| Technology | |
| Memory Speed | 1600 MHz, 2133 MHz, 2400 MHz, 2666 MHz, 2800 MHz, 2933 MHz, 3000 MHz, 3200 MHz, 3333 MHz, 3400 MHz, 3466 MHz, 3600 MHz, 3733 MHz, 4000 MHz, 4133 MHz, 4266 MHz, 4400 MHz, 4600 MHz, 4800 MHZ, 4866 MHz, 5000 MHz, 5066, 5066 MHz, 5200MHZ, 5333, 5333 MHz, 5400Mhz, 5600 MHz, 5800, 6000MHz, 6200MHZ, 6400Mhz, 6600Mhz, 6800Mhz, 7000 MHz, 7200MHZ, 7400MHZ, 7600MHZ, 7800MHZ, 8000MHZ, 8200MHz, 8266MHz, 8400 MHZ, 8600MHZ, 8666 MHZ, 8800, 8800MHz, 8933MHz, 9066MHz, 9200MHz |
| Max Memory Size | |
| Memory Slot | |
| PCI-E X16 | |
| PCI-E GEN | PCIe 5.0 |
| PCI-E Slots (M.2) | |
| SATAIII | |
| Communication module | |
| Part Number | |
| Warranty |
