Nzxt H7 Flow RGB 2024 Black Mid Tower Case
0 EGP
- ATX, M-ATX, M-ITX, E-ATX Support
- Steel Frame & Dark Tinted Glass
- 2 x 2.5″ & 2 x 2.5/3.5″ Drive Bays
- 7 x Expansion Slots
- USB 3.2 Gen 1 & Gen 2 | 3.5mm Audio Jack
- Supports GPUs up to 16.1″ Long
- Supports CPU Coolers up to 7.3″ Tall
- 1.3″ Cable Management Space
- Pre-Installed F360 RGB 3-Fan Array
- Supports AiO Radiators
Out Of Stock.
| MODEL | |
|---|---|
| CASE SIZE | |
| PANEL | |
| Motherboard Type | |
| FANS INCLUDED | |
| Expansion Slots | |
| Fan Support | |
| Radiator Support | |
| GPU Length | |
| CPU Height | |
| PSU SUPPORT | |
| Pre-installed PSU | |
| I/O Ports | |
| 3.5“ Drive Bays | |
| 2.5" Drive Bays | |
| Color | |
| Part Number | |
| Warranty |
Nzxt H7 Flow RGB 2024 Black Mid Tower Case
The H7 Flow RGB revolutionizes GPU cooling in a classic mid-tower form factor. Its vertical PSU layout allows space for 3 x 120mm bottom fans, offering efficient cooling without expanding the case footprint.
-
Supports three bottom-mounted 120mm fans for direct GPU cooling while retaining a narrow mid-tower footprint.
-
Comes equipped with a F360 RGB Core single-frame fan for exceptional out-of-the-box cooling and RGB lighting.
-
High-performance mesh panels maximize airflow for both intake and exhaust, as well as filter dust.
-
Supports up to 420mm radiators in the front and 360mm radiators in the top for powerful cooling potential.
-
Intuitive cable management system with wide channels, built-in hooks, and included straps for easy routing.
-
Capacity for up to 10 fans in total: 3 up top, 3 in front, 3 on bottom, and 1 in the rear.
-
Conveniently access 2 x USB-A and 1 x USB-C ports located on the top panel.
-
Tool-less access to the front, top, and side panels makes building and upgrading a breeze.
Inside the Box
-
H7 Flow RGB
-
F360 RGB Core (pre-installed, case version)
-
Installation Accessories
-
Manual
Nzxt H7 Flow RGB 2024 Black Mid Tower Case
Tech Specs
Key Specs
- Motherboard Support:E-ATX (Up to 277mm), ATX, Micro-ATX, Mini-ITX
- Enclosure Type:Mid-Tower
- Case Material:SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black)
Dimensions
- Height (With Feet):544 mm
- Width:244 mm
- Depth:468 mm
- Weight:11.13 kg
Compatibility & Clearance
- CPU Cooler Height:Up to 185mm
- GPU Length:Up to 410 mm
- PSU Length:Up to 200 mm
- Cable Management:Up to 34.5 mm
- Top Mounted 140mm / 280mm Radiator & Fan Combined Thickness:Up to 57 mm
Front I/O Ports
- USB 3.2 Gen 1 Type-A:2
- USB 3.2 Gen 2×2 Type-C (20 Gbps):1
- Headset Audio Jack:1
Expansion Slots
- Standard:7
- Vertical:0
Drive Bays
- 2.5″:2+2
- 3.5″:2
Fan Support
- Front:3 x 120 mm / 3 x 140 mm (1 x F360 RGB Core included)
- Top:3 x 120 mm / 2 x 140 mm
- Bottom:3 x 120 mm
- Rear:1 x 120 mm / 1 x 140 mm
- Filters:High-Performance Mesh
Radiator Support
- Front:Up to 420 mm
- Top:Up to 360mm
- Rear:Up to 140mm
Fan Specs
- Model:F360 RGB Core Fan (Case Version)
- Speed:1,700 ± 200 RPM
- Airflow:50.1 CFM
- Static:1.27 mm-H₂O
- Noise:23.3 dBA
- Fan Connector:3-pin
General
- Model Number:CM-H72FB-R1 (Black)
- UPC:810074845571 (Black)
- EAN:5056547205526 (Black)
